EC25 Series
Manufacturer: Quectel
Beta
⌘K
CELLULAR MODULE, EDGE, GNSS, GSM, LTE-FDD, LTE-TDD, WCDMA, 3V TO 3.6V, 30MM X 51MM X 4.9MM
| Part | Voltage - Supply [Max] | Voltage - Supply [Min] | Utilized IC / Part | Package / Case | RF Family/Standard | Serial Interfaces | Antenna Type | Data Rate | Protocol | Operating Temperature [Max] | Operating Temperature [Min] | Mounting Type | Sensitivity | Frequency | Power - Output | Modulation | Current - Transmitting | Current - Receiving |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 Quectel | 3.6 V | 3 V | MDM9207-0 | Module | Cellular Navigation | I2C PCM UART USB | Antenna Not Included | 150 Mbps | BeiDou Galileo GLONASS GNSS GPS LTE UMTS WCDMA | 75 ░C | -35 °C | Card Edge | ||||||
 Quectel | 3.6 V | 3 V | Module | Cellular Navigation | I2C PCM UART USB | Antenna Not Included | 150 Mbps | BeiDou EDGE Galileo GLONASS GNSS GPS GSM LTE WCDMA | 75 ░C | -35 °C | Card Edge | |||||||
 Quectel | 3.6 V | 3 V | Module | Cellular Navigation | I2C PCM UART USB | Antenna Not Included | 480 Mbps | BeiDou EDGE Galileo GLONASS GNSS GPS GSM LTE WCDMA | 75 ░C | -35 °C | Card Edge Surface Mount | -110.5 dBm | 1.561 GHz 1.575 GHz 1.602 GHz 1.8 GHz 900 MHz | 33 dBm | 16QAM 64QAM 8PSK GMSK | |||
 Quectel | 3.6 V | 3 V | MDM9307-0 | Module | Cellular Navigation | I2C PCM UART USB | Antenna Not Included | 150 Mbps | BeiDou Galileo GLONASS GNSS GPS LTE | 75 ░C | -35 °C | Card Edge | 30 mA | 30 mA | ||||
Quectel | 3.6 V | 3 V | Module | Cellular Navigation | I2C PCM UART USB | Antenna Not Included | 480 Mbps | BeiDou EDGE Galileo GLONASS GNSS GPS LTE WCDMA | 75 ░C | -35 °C | Card Edge Surface Mount | -110.5 dBm | 1.561 GHz 1.575 GHz 1.602 GHz | 33 dBm | 16QAM 64QAM 8PSK GMSK | |||
 Quectel | 3.6 V | 3 V | MDM9207-0 | Module | Cellular Navigation | I2C PCM UART USB | Antenna Not Included | 480 Mbps | BeiDou EDGE Galileo GLONASS GNSS GPS LTE WCDMA | 75 ░C | -35 °C | Card Edge Surface Mount | -110.5 dBm | 1.561 GHz 1.575 GHz 1.602 GHz | 33 dBm | 16QAM 64QAM 8PSK GMSK | ||
Quectel | 3.6 V | 3 V | MDM9207-0 | Module | Cellular | I2C PCM UART USB | Antenna Not Included | 480 Mbps | LTE WCDMA | 75 ░C | -35 °C | Card Edge Surface Mount | 1.561 GHz 1.575 GHz 1.602 GHz | 33 dBm | 16QAM 64QAM 8PSK GMSK | |||
Quectel | 3.6 V | 3 V | MDM9207-0 | Module | Cellular Navigation | I2C PCM UART USB | Antenna Not Included | 150 Mbps | BeiDou Galileo GLONASS GNSS GPS LTE UMTS WCDMA | 75 ░C | -35 °C | Card Edge | 22 mA | 22 mA | ||||
Quectel | 3.6 V | 3 V | MDM9207-0 | Module | Cellular Navigation | I2C PCM UART USB | Antenna Not Included | 480 Mbps | BeiDou EDGE Galileo GLONASS GNSS GPS LTE WCDMA | 75 ░C | -35 °C | Card Edge Surface Mount | -110.5 dBm | 1.561 GHz 1.575 GHz 1.602 GHz | 33 dBm | 16QAM 64QAM 8PSK GMSK | ||
Quectel | 3.6 V | 3 V | Module | Cellular Navigation | I2C PCM UART USB | Antenna Not Included | 480 Mbps | BeiDou EDGE Galileo GLONASS GNSS GPS GSM LTE WCDMA | 75 ░C | -35 °C | Card Edge Surface Mount | -111 dBc | 1.561 GHz 1.575 GHz 1.602 GHz 1.8 GHz 1.9 GHz 850 MHz 900 MHz | 33 dBm | 16QAM 64QAM 8PSK GMSK |
