HW1S Series
Manufacturer: IDEC
Beta
⌘K
ROTARY SWITCH, 2 POSITION, 2 POLE, 90 °, 10 A, 110 V, HW SERIES
| Part | Type | Switch Function | Current Rating (Amps) | Panel Cutout Dimensions [diameter] | Number of Positions | Voltage Rating - DC | Mounting Type | Operating Temperature [Min] | Operating Temperature [Max] | Voltage Rating - AC | Ingress Protection | Circuit | Illumination | Termination Style | Requires | Actuator Type | Approval Agency | Mechanical Life | Depth Behind Flange [z] |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 IDEC | Standard | Off-On | 10 A | 22.3 mm | 2 | 24 V | Panel Mount | -25 °C | 60 °C | 110 V | IP65 - Dust Tight Water Resistant | DPST-NO | Non-Illuminated | Screw Terminal | |||||
 IDEC | Standard | Off-Off-Off-Off-On Off-Off-Off-On-Off Off-On-Off-Off-Off On-Off-Off-Off-Off | 10 A | 22.3 mm | 5 | 24 V | Panel Mount | -25 °C | 60 °C | 110 V | IP65 - Dust Tight Water Resistant | 4PST-2NO/2NC | Non-Illuminated | Screw Terminal | |||||
IDEC | |||||||||||||||||||
IDEC | |||||||||||||||||||
IDEC | Standard | Off-Off-On-Off Off-On-Off-Off On-Off-Off-Off | 10 A | 22.3 mm | 4 | 24 V | Panel Mount | -25 °C | 60 °C | 110 V | IP65 - Dust Tight Water Resistant | 3PST-2NC/1NO | Non-Illuminated | Screw Terminal | |||||
IDEC | Maintained | 22.3 mm | Non-Illuminated | Contact Block(s) | Selector | ||||||||||||||
 IDEC | |||||||||||||||||||
 IDEC | Maintained | 22.3 mm | Non-Illuminated | Contact Block(s) | Selector | ||||||||||||||
IDEC | Standard | Mom-On-Mom | 10 A | 22.3 mm | 24 V | Panel Mount | -25 °C | 60 °C | 110 V | IP65 - Dust Tight Water Resistant | 4PST-NC | Non-Illuminated | Screw Terminal | CCC CE CSA TUV UL | 500000 Cycles | 89.4 mm | |||
IDEC |
