MPL-SE6040 Series
Manufacturer: Monolithic Power Systems Inc.
Beta
⌘K
POWER INDUCTOR (SMD), 8.2 ΜH, 4 A, SEMISHIELDED, 3.6 A, MPL-SE SERIES
| Part | Package / Case | Current Rating (Amps) | Inductance Frequency - Test | Current - Saturation (Isat) | Inductance | DC Resistance (DCR) | Shielding | Height - Seated (Max) | Height - Seated (Max) [Max] | Size / Dimension [y] | Size / Dimension [x] | Size / Dimension [x] | Size / Dimension [y] | Mounting Type | Operating Temperature [Max] | Operating Temperature [Min] | Size / Dimension [y] |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 Monolithic Power Systems Inc. | Nonstandard 2 Lead | 4 A | 100 kHz | 3.6 A | 8.2 µH | 39 mOhm | Shielded | 4 mm | 0.157 in | 6.4 mm | 6.6 mm | 0.26 in | 0.252 in | Surface Mount | 125 °C | -40 C | |
 Monolithic Power Systems Inc. | Nonstandard 2 Lead | 3.8 A | 100 kHz | 3.4 A | 10 µH | 41 mOhm | Semi-Shielded Shielded | 4 mm | 0.157 in | 6 mm | 0.236 in | 0.236 " | Surface Mount | 125 °C | -40 C | 6 mm | |
 Monolithic Power Systems Inc. | Nonstandard 2 Lead | 2.35 A | 100 kHz | 2.25 A | 22 µH | 97 mOhm | Shielded | 4 mm | 0.157 in | 6 mm | 0.236 in | 0.236 " | Surface Mount | 125 °C | -40 C | 6 mm | |
Monolithic Power Systems Inc. | Nonstandard 2 Lead | 4.4 A | 100 kHz | 4.1 A | 6.8 µH | 33 mOhm | Shielded | 4 mm | 0.157 in | 6 mm | 0.236 in | 0.236 " | Surface Mount | 125 °C | -40 C | 6 mm | |
Monolithic Power Systems Inc. | Nonstandard 2 Lead | 6.8 A | 100 kHz | 8.9 A | 1.5 µH | 11.5 mOhm | Shielded | 4 mm | 0.157 in | 6 mm | 0.236 in | 0.236 " | Surface Mount | 125 °C | -40 C | 6 mm | |
Monolithic Power Systems Inc. | Nonstandard 2 Lead | 6.3 A | 100 kHz | 7.2 A | 2.2 µH | 14.5 mOhm | Shielded | 4 mm | 0.157 in | 6 mm | 0.236 in | 0.236 " | Surface Mount | 125 °C | -40 C | 6 mm | |
Monolithic Power Systems Inc. | Nonstandard 2 Lead | 5.2 A | 100 kHz | 5 A | 4.7 ÁH | 23 mOhm | Shielded | 4 mm | 0.157 in | 6 mm | 0.236 in | 0.236 " | Surface Mount | 125 °C | -40 C | 6 mm | |
Monolithic Power Systems Inc. | Nonstandard 2 Lead | 2.8 A | 100 kHz | 2.7 A | 15 µH | 70 mOhm | Shielded | 4 mm | 0.157 in | 6 mm | 0.236 in | 0.236 " | Surface Mount | 125 °C | -40 C | 6 mm | |
Monolithic Power Systems Inc. | Nonstandard 2 Lead | 5.6 A | 100 kHz | 5.6 A | 3.3 µH | 19.5 mOhm | Shielded | 4 mm | 0.157 in | 6 mm | 0.236 in | 0.236 " | Surface Mount | 125 °C | -40 C | 6 mm |
