RB160MM-90TF Series

Schottky Barrier Diode (AEC-Q101 Qualified)

Catalog

Schottky Barrier Diode (AEC-Q101 Qualified)

Part	Operating Temperature - Junction	Speed	Mounting Type	Voltage - DC Reverse (Vr) (Max) [Max]	Supplier Device Package	Current - Average Rectified (Io)	Current - Reverse Leakage @ Vr	Technology	Package / Case	Voltage - Forward (Vf) (Max) @ If	Grade	Qualification
Rohm Semiconductor RB160L-40TE25	150 °C	200 mA 500 ns	Surface Mount	40 V	PMDS	1 A	100 çA	Schottky	DO-214AC SMA	550 mV
Rohm Semiconductor RB160M-90TR	150 °C	200 mA 500 ns	Surface Mount		PMDU	1 A		Schottky	SOD-123F	730 mV
Rohm Semiconductor RB160MM-50TR	150 °C	200 mA 500 ns	Surface Mount	40 V	PMDU	1 A		Schottky	SOD-123F	510 mV
Rohm Semiconductor RB160M-40TR	150 °C	200 mA 500 ns	Surface Mount	40 V	PMDU	1 A		Schottky	SOD-123F	510 mV
Rohm Semiconductor RB160MM-90TR	150 °C	200 mA 500 ns	Surface Mount		PMDU	1 A		Schottky	SOD-123F	730 mV
Rohm Semiconductor RB160L-90TE25	150 °C	200 mA 500 ns	Surface Mount		PMDS	1 A		Schottky	DO-214AC SMA	730 mV
Rohm Semiconductor RB160MM-90TFTR	150 °C	200 mA 500 ns	Surface Mount		PMDU	1 A		Schottky	SOD-123F	730 mV	Automotive	AEC-Q101
Rohm Semiconductor RB160VAM-40TR	150 °C	200 mA 500 ns	Surface Mount	40 V	TUMD2M	1 A	50 µA	Schottky	2-SMD Flat Leads	550 mV
Rohm Semiconductor RB160MM-40TR	150 °C	200 mA 500 ns	Surface Mount	40 V	PMDU	1 A		Schottky	SOD-123F	510 mV
Rohm Semiconductor RB160SS-40T2R	150 °C	200 mA 500 ns	Surface Mount	40 V	KMD2	1 A	50 µA	Schottky	2-SMD No Lead	550 mV

Schottky Barrier Diode (AEC-Q101 Qualified)

• Small power mold type (TUMD2M), High reliability, Low VF

RB160MM-90TF is the high reliability Automotive Schottky Barrier Diode, suitable for general rectification.
