846-014 Series
Manufacturer: EDAC Inc.
Beta
⌘K
CONN EDGE SGL FMALE 14POS 0.125
| Part | Termination Rows | Material - Insulation | Contact Material | Contact Type | Mounting Type | Read Out | Flange Feature | Card Thickness [Max] | Card Thickness [Min] | Number of Positions/Bay/Row | Gender | Contact Finish Thickness | Contact Finish Thickness | Pitch | Pitch | Number of Positions | Number of Rows | Operating Temperature [Max] | Operating Temperature [Min] | Card Type | Contact Finish | Color | Termination | Termination Rows [custom] | Flange Feature [diameter] | Flange Feature [diameter] | Number of Rows [custom] |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 EDAC Inc. | 1 | Diallyl Phthalate (DAP) | Copper Alloy | Cantilever | Through Hole | Single | 4-40 Flush Mount Threaded Insert Top Opening | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 14 | Female | 0.25 Ám | 10 Áin | 3.18 mm | 0.125 in | 14 | 1 | 125 °C | -40 C | Non Specified - Single Edge | Gold | Green | Solder | ||||
 EDAC Inc. | Diallyl Phthalate (DAP) | Copper Alloy | Cantilever | Through Hole | Dual | Floating Bobbin Top Mount Opening | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 7 | Female | 0.25 Ám | 10 Áin | 3.18 mm | 0.125 in | 14 | 125 °C | -40 C | Non Specified - Dual Edge | Gold | Green | Wire Wrap | 2 | 0.116 " | 2.95 mm | 2 | ||
 EDAC Inc. | 1 | Diallyl Phthalate (DAP) | Copper Alloy | Cantilever | Through Hole | Single | Flush Mount M3 Threaded Insert Top Opening | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 14 | Female | 0.25 Ám | 10 Áin | 3.18 mm | 0.125 in | 14 | 1 | 125 °C | -40 C | Non Specified - Single Edge | Gold | Green | Wire Wrap | ||||
 EDAC Inc. | Diallyl Phthalate (DAP) | Copper Alloy | Cantilever | Right Angle Through Hole | Dual | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 7 | Female | 0.25 Ám | 10 Áin | 3.18 mm | 0.125 in | 14 | 125 °C | -40 C | Non Specified - Dual Edge | Gold | Green | Solder | 2 | 0.128 " | 3.25 mm | 2 | |||
 EDAC Inc. | Diallyl Phthalate (DAP) | Copper Alloy | Cantilever | Right Angle Through Hole | Dual | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 7 | Female | 0.25 Ám | 10 Áin | 3.18 mm | 0.125 in | 14 | 125 °C | -40 C | Non Specified - Dual Edge | Gold | Green | Solder | 2 | 0.156 " | 3.96 mm | 2 | |||
 EDAC Inc. | 1 | Diallyl Phthalate (DAP) | Copper Alloy | Cantilever | Through Hole | Single | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 14 | Female | 0.25 Ám | 10 Áin | 3.18 mm | 0.125 in | 14 | 1 | 125 °C | -40 C | Non Specified - Single Edge | Gold | Green | Solder Eyelet(s) | 0.156 " | 3.96 mm | |||
 EDAC Inc. | Diallyl Phthalate (DAP) | Copper Alloy | Cantilever | Through Hole | Dual | Flush Mount Side Opening Unthreaded | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 7 | Female | 0.25 Ám | 10 Áin | 3.18 mm | 0.125 in | 14 | 125 °C | -40 C | Non Specified - Dual Edge | Gold | Green | Solder Eyelet(s) | 2 | 0.128 " | 3.25 mm | 2 | ||
 EDAC Inc. | 1 | Diallyl Phthalate (DAP) | Copper Alloy | Cantilever | Through Hole | Single | M3 Threaded Insert Top Mount Opening | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 14 | Female | 0.25 Ám | 10 Áin | 3.18 mm | 0.125 in | 14 | 1 | 125 °C | -40 C | Non Specified - Single Edge | Gold | Green | Wire Wrap | ||||
 EDAC Inc. | Diallyl Phthalate (DAP) | Copper Alloy | Cantilever | Right Angle Through Hole | Dual | Flush Mount Side Opening Unthreaded | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 7 | Female | 0.25 Ám | 10 Áin | 3.18 mm | 0.125 in | 14 | 125 °C | -40 C | Non Specified - Dual Edge | Gold | Green | Solder | 2 | 0.128 " | 3.25 mm | 2 | ||
 EDAC Inc. | 1 | Diallyl Phthalate (DAP) | Copper Alloy | Cantilever | Through Hole | Single | Flush Mount Top Opening Unthreaded | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 14 | Female | 0.25 Ám | 10 Áin | 3.18 mm | 0.125 in | 14 | 1 | 125 °C | -40 C | Non Specified - Single Edge | Gold | Green | Solder Eyelet(s) | 0.128 " | 3.25 mm |
