G11MA7-P Series
Manufacturer: ODU
Beta
⌘K
CONN RCPT FMALE 10P SOLDER CUP
| Part | Operating Temperature [Max] | Operating Temperature [Min] | Fastening Type | Contact Material | Mounting Feature | Ingress Protection | Mounting Type | Shell Size - Insert | Connector Type | Contact Finish - Mating | Shielding | Shell Material | Primary Material | Number of Positions | Orientation | Color | Insert Material | Applications | Current Rating (Amps) |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
120 °C | -50 °C | Detent Lock Push-Pull | Brass | Bulkhead - Rear Side Nut | IP50 - Dust Protected | Panel Mount | 1 | Receptacle Female Sockets | Gold | Unshielded | Polysulfone (PSU) | Plastic | 10 | A | Gray Green | Polyetheretherketone (PEEK) | Industrial Medical Military Testing Equipment & Measurement | 2.75 A | |
120 °C | -50 °C | Detent Lock Push-Pull | Brass | Bulkhead - Rear Side Nut | IP50 - Dust Protected | Panel Mount | 1 | Receptacle Female Sockets | Gold | Unshielded | Polysulfone (PSU) | Plastic | 14 | A | Gray Green | Polyetheretherketone (PEEK) | Industrial Medical Military Testing Equipment & Measurement | 2.5 A | |
120 °C | -50 °C | Detent Lock Push-Pull | Brass | Bulkhead - Rear Side Nut | IP50 - Dust Protected | Panel Mount | 1 | Receptacle Female Sockets | Gold | Unshielded | Polysulfone (PSU) | Plastic | 2 | A | Gray Green | Polyetheretherketone (PEEK) | Industrial Medical Military Testing Equipment & Measurement | 14 A | |
120 °C | -50 °C | Detent Lock Push-Pull | Brass | Bulkhead - Rear Side Nut | IP50 - Dust Protected | Panel Mount | 1 | Receptacle Female Sockets | Gold | Unshielded | Polysulfone (PSU) | Plastic | 4 | A | Gray Red | Polyetheretherketone (PEEK) | Industrial Medical Military Testing Equipment & Measurement | 10 A | |
120 °C | -50 °C | Detent Lock Push-Pull | Brass | Bulkhead - Rear Side Nut | IP50 - Dust Protected | Panel Mount | 1 | Receptacle Female Sockets | Gold | Unshielded | Polysulfone (PSU) | Plastic | 7 | A | Polyetheretherketone (PEEK) | Industrial Medical Military Testing Equipment & Measurement | 4.55 A | ||
120 °C | -50 °C | Detent Lock Push-Pull | Brass | Bulkhead - Rear Side Nut | IP50 - Dust Protected | Panel Mount | 1 | Receptacle Female Sockets | Gold | Unshielded | Polysulfone (PSU) | Plastic | 4 | A | Gray | Polyetheretherketone (PEEK) | Industrial Medical Military Testing Equipment & Measurement | 10 A | |
120 °C | -50 °C | Detent Lock Push-Pull | Brass | Bulkhead - Rear Side Nut | IP50 - Dust Protected | Panel Mount | 1 | Receptacle Female Sockets | Gold | Unshielded | Polysulfone (PSU) | Plastic | 9 | A | Gray | Polyetheretherketone (PEEK) | Industrial Medical Military Testing Equipment & Measurement | 2.75 A | |
120 °C | -50 °C | Detent Lock Push-Pull | Brass | Bulkhead - Rear Side Nut | IP50 - Dust Protected | Panel Mount | 1 | Receptacle Female Sockets | Gold | Unshielded | Polysulfone (PSU) | Plastic | 14 | A | Gray | Polyetheretherketone (PEEK) | Industrial Medical Military Testing Equipment & Measurement | 2.5 A | |
120 °C | -50 °C | Detent Lock Push-Pull | Brass | Bulkhead - Rear Side Nut | IP50 - Dust Protected | Panel Mount | 1 | Receptacle Female Sockets | Gold | Unshielded | Polysulfone (PSU) | Plastic | 6 | A | Gray | Polyetheretherketone (PEEK) | Industrial Medical Military Testing Equipment & Measurement | 4.55 A | |
120 °C | -50 °C | Detent Lock Push-Pull | Brass | Bulkhead - Rear Side Nut | IP50 - Dust Protected | Panel Mount | 1 | Receptacle Female Sockets | Gold | Unshielded | Polysulfone (PSU) | Plastic | 6 | A | Blue Gray | Polyetheretherketone (PEEK) | Industrial Medical Military Testing Equipment & Measurement | 4.55 A |
