1393644 Series
Manufacturer: TE Connectivity AMP Connectors
Beta
⌘K
CONN DIN PLUG 96POS PCB RA GOLD
| Part | Material Flammability Rating | Operating Temperature [Min] | Operating Temperature [Max] | Material - Insulation | Mounting Type | Contact Finish | Termination | Number of Rows [custom] | Number of Positions | Style | Number of Positions Loaded | Pitch | Pitch | Level, Class [custom] | Connector Type | Number of Positions Loaded | Style | Features |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 TE Connectivity AMP Connectors | UL94 V-0 | -55 C | 125 °C | Glass Filled Polybutylene Terephthalate (PBT) Polyester | Right Angle Through Hole | Gold Gold-Palladium | Solder | 3 | 96 | C | 64 | 0.1 " | 2.54 mm | 1 | Plug Male Pins | |||
TE Connectivity AMP Connectors | UL94 V-0 | -55 C | 125 °C | Glass Filled Polybutylene Terephthalate (PBT) Polyester | Right Angle Through Hole | Gold Gold-Palladium | Solder | 3 | 96 | C | 0.1 " | 2.54 mm | Plug Male Pins | All | ||||
 TE Connectivity AMP Connectors | UL94 V-0 | -55 C | 125 °C | Glass Filled Polybutylene Terephthalate (PBT) Polyester | Right Angle Through Hole | Gold Gold-Palladium | Solder | 3 | 48 | C/2 | 0.1 " | 2.54 mm | 1 | Plug Male Pins | All | 1/2 C | ||
 TE Connectivity AMP Connectors | UL94 V-0 | -55 C | 125 °C | Glass Filled Polybutylene Terephthalate (PBT) Polyester | Right Angle Through Hole | Gold Gold-Palladium | Solder | 3 | 30 | C/3 (1/3 C) | 0.1 " | 2.54 mm | Plug Male Pins | All | ||||
 TE Connectivity AMP Connectors | UL94 V-0 | -55 C | 125 °C | Glass Filled Polybutylene Terephthalate (PBT) Polyester | Right Angle Through Hole | Gold Gold-Palladium | Solder | 3 | 96 | C | 64 | 0.1 " | 2.54 mm | Plug Male Pins | ||||
 TE Connectivity AMP Connectors | UL94 V-0 | -55 C | 125 °C | Glass Filled Polybutylene Terephthalate (PBT) Polyester | Right Angle Through Hole | Gold Gold-Palladium | Solder | 3 | 96 | C | 0.1 " | 2.54 mm | Plug Male Pins | All | Board Lock | |||
TE Connectivity AMP Connectors | UL94 V-0 | -55 C | 125 °C | Glass Filled Polybutylene Terephthalate (PBT) Polyester | Right Angle Through Hole | Gold Gold-Palladium | Solder | 2 | 64 | B | 32 | 0.1 " | 2.54 mm | Plug Male Pins | ||||
TE Connectivity AMP Connectors | UL94 V-0 | -55 C | 125 °C | Glass Filled Polybutylene Terephthalate (PBT) Polyester | Right Angle Through Hole | Gold Gold-Palladium | Solder | 3 | 96 | C | 64 | 0.1 " | 2.54 mm | Plug Male Pins | Board Lock | |||
 TE Connectivity AMP Connectors | UL94 V-0 | -55 C | 125 °C | Glass Filled Polybutylene Terephthalate (PBT) Polyester | Right Angle Through Hole | Gold Gold-Palladium | Solder | 3 | 48 | C/2 | 0.1 " | 2.54 mm | Plug Male Pins | All | 1/2 C |
