UPD2415 Series
Manufacturer: Sensata-Crydom
Beta
⌘K
RELAY SSR 14MA 8V DC-IN 15A 280V AC-OUT 8-PIN SIP
| Part | Mounting Type | Termination Style | Package / Case | Supplier Device Package | Circuit | Voltage - Input [Min] | Voltage - Input [Max] | Voltage - Load [Min] | Voltage - Load [Max] | Operating Temperature [Max] | Operating Temperature [Min] | Output Type | Load Current | Approval Agency |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 Sensata-Crydom | Through Hole | PC Pin | 6-SIP | 6-SIP | 3PST-NO (3 Form A) | 4.5 V | 8 VDC | 24 V | 280 V | 80 °C | -40 C | AC Zero Cross | 15 A | CE cURus |
 Sensata-Crydom | Through Hole | PC Pin | 6-SIP | 6-SIP | SPST-NO (1 Form A) x 2 | 3 V | 15 V | 24 V | 280 V | 80 °C | -40 C | AC Zero Cross | 15 A | CE cURus |
 Sensata-Crydom | Chassis Mount | Quick Connect - 0.250" (6.3mm) | Module | SPST-NO (1 Form A) x 2 | 3 V | 15 V | 24 V | 280 V | 80 °C | -40 C | AC Zero Cross | 15 A | CE cURus | |
Sensata-Crydom | Through Hole | PC Pin | 6-SIP | 6-SIP | SPST-NO (1 Form A) x 2 | 3 V | 15 V | 24 V | 280 V | 80 °C | -40 C | AC | 15 A | CE cURus |
Sensata-Crydom | Through Hole | PC Pin | 6-SIP | 6-SIP | 3PST-NO (3 Form A) | 4.5 V | 8 VDC | 24 V | 280 V | 80 °C | -40 C | AC | 15 A | CE cURus |
 Sensata-Crydom | Chassis Mount | Quick Connect - 0.250" (6.3mm) | Module | 3PST-NO (3 Form A) | 4.5 V | 8 VDC | 24 V | 280 V | 80 °C | -40 C | AC Zero Cross | 15 A | CE cURus | |
 Sensata-Crydom | Through Hole | PC Pin | 6-SIP | 6-SIP | 3 V | 32 VDC | 24 V | 280 V | 80 °C | -40 C | AC | 15 A | CE cURus | |
Sensata-Crydom | Chassis Mount | Quick Connect - 0.250" (6.3mm) | Module | 3 V | 32 VDC | 24 V | 280 V | 80 °C | -40 C | AC Zero Cross | 15 A | CE cURus | ||
Sensata-Crydom | Chassis Mount | Quick Connect - 0.250" (6.3mm) | Module | 3PST-NO (3 Form A) | 4.5 V | 8 VDC | 24 V | 280 V | 80 °C | -40 C | AC | 15 A | CE cURus | |
Sensata-Crydom | Chassis Mount | Quick Connect - 0.250" (6.3mm) | Module | 3 V | 32 VDC | 24 V | 280 V | 80 °C | -40 C | AC | 15 A | CE cURus |
