RACM40-S Series
Manufacturer: Recom Power
Beta
⌘K
SWITCHING POWER SUPPLIES 40W 5V 8000MA
| Part | Type | Current - Output 1 | Voltage - Isolation | Features | Voltage - Output 1 | Efficiency | Size / Dimension [y] | Size / Dimension [z] | Size / Dimension [y] | Size / Dimension [z] | Size / Dimension [x] | Size / Dimension [x] | Applications | Approval Agency | Power (Watts) | Number of Outputs | Mounting Type | Operating Temperature [Min] | Operating Temperature [Max] | Minimum Load Required |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 Recom Power | Enclosed | 8 A | 4000 V | Adjustable Output DC Input Capable Universal Input | 5 V | 90 % | 2.38 in | 1.31 " | 60.5 mm | 33.3 mm | 91.4 mm | 3.6 " | Medical | CE cURus | 40 W | 1 | Chassis Mount | -40 °C | 85 °C | |
 Recom Power | Enclosed | 840 mA | 4000 V | Adjustable Output DC Input Capable Universal Input | 48 V | 93 % | 2.38 in | 1.31 " | 60.5 mm | 33.3 mm | 91.4 mm | 3.6 " | Medical | CE cURus | 40 W | 1 | Chassis Mount | -40 °C | 85 °C | |
 Recom Power | Open Frame | 1.67 A | 4000 V | Adjustable Output DC Input Capable Universal Input | 24 V | 92 % | 2 in | 1.04 in | 50.8 mm | 26.5 mm | 76.2 mm | 3 " | Medical | CE cURus | 40 W | 1 | Chassis Mount | -40 °C | 85 °C | |
 Recom Power | Open Frame | 3.34 A | 4000 V | Adjustable Output DC Input Capable Universal Input | 12 V | 92 % | 2 in | 1.04 in | 50.8 mm | 26.5 mm | 76.2 mm | 3 " | Medical | CE cURus | 40 W | 1 | Chassis Mount | -40 °C | 85 °C | |
 Recom Power | Open Frame | 8 A | 4000 V | Adjustable Output DC Input Capable Universal Input | 5 V | 90 % | 2 in | 1.04 in | 50.8 mm | 26.5 mm | 76.2 mm | 3 " | Medical | CE cURus | 40 W | 1 | Chassis Mount | -40 °C | 85 °C | |
 Recom Power | Enclosed | 1.67 A | 4000 V | Adjustable Output DC Input Capable Universal Input | 24 V | 92 % | 2.38 in | 1.31 " | 60.5 mm | 33.3 mm | 91.4 mm | 3.6 " | Medical | CE cURus | 40 W | 1 | Chassis Mount | -40 °C | 85 °C | |
Recom Power | Open Frame | 1.67 A | 4000 V | Adjustable Output DC Input Capable Universal Input | 24 V | 92 % | 2 in | 1.04 in | 50.8 mm | 26.5 mm | 76.2 mm | 3 " | Medical | CE cURus | 40 W | 1 | Chassis Mount | -40 °C | 85 °C | |
Recom Power | Open Frame | 8 A | 4000 V | Adjustable Output DC Input Capable Universal Input | 5 V | 90 % | 2 in | 1.04 in | 50.8 mm | 26.5 mm | 76.2 mm | 3 " | Medical | CE cURus | 40 W | 1 | Chassis Mount | -40 °C | 85 °C | |
Recom Power | Enclosed | 3.34 A | 4000 V | Adjustable Output DC Input Capable Universal Input | 12 V | 92 % | 2.38 in | 1.31 " | 60.5 mm | 33.3 mm | 91.4 mm | 3.6 " | Medical | CE cURus | 40 W | 1 | Chassis Mount | -40 °C | 85 °C | |
Recom Power | Open Frame | 840 mA | 4000 V | Adjustable Output DC Input Capable Universal Input | 48 V | 93 % | 2 in | 1.04 in | 50.8 mm | 26.5 mm | 76.2 mm | 3 " | Medical | CE cURus | 40 W | 1 | Chassis Mount | -40 °C | 85 °C |
