Schaffner FN2220 Series
Manufacturer: TE Connectivity AMP Connectors
Beta
⌘K
LINE FLTR 500VDC 600A CHASS MNT
| Part | Approval Agency | Current | Frequency - Operating | Voltage - Rated DC | Mounting Type | Filter Type | Configuration | Applications | Termination Style | Operating Temperature [Min] | Operating Temperature [Max] | Voltage - Rated DC |
|---|---|---|---|---|---|---|---|---|---|---|---|---|
 TE Connectivity AMP Connectors | CE CSA ENEC UKCA UR | 600 A | DC | 500 V | Chassis Mount | DC | Two Stage | General Purpose | Quick Connect Threaded Post (M10) | -40 C | 100 °C | |
 TE Connectivity AMP Connectors | CE cURus ENEC UKCA | 600 A | DC | Chassis Mount | DC | Two Stage | General Purpose | Terminal Post | -40 C | 100 °C | ||
 TE Connectivity AMP Connectors | CE CSA ENEC UKCA UR | 150 A | DC | 1000 V | Chassis Mount | DC | Two Stage | General Purpose | Quick Connect Threaded Post (M10) | -40 C | 100 °C | 1 kV |
 TE Connectivity AMP Connectors | CE CSA ENEC UKCA UR | 600 A | DC | 1000 V | Chassis Mount | DC | Two Stage | General Purpose | Quick Connect Threaded Post (M10) | -40 C | 100 °C | 1 kV |
 TE Connectivity AMP Connectors | CE cURus ENEC UKCA | 600 A | DC | Chassis Mount | Three Phase (Wye) | Two Stage | General Purpose | Terminal Post | -40 C | 100 °C | ||
 TE Connectivity AMP Connectors | CE CSA ENEC UKCA UR | 150 A | DC | 1000 V | Chassis Mount | DC | Two Stage | General Purpose | Quick Connect Threaded Post (M10) | -40 C | 100 °C | 1 kV |
TE Connectivity AMP Connectors | CE cURus ENEC UKCA | 600 A | DC | Chassis Mount | Three Phase (Wye) | Two Stage | General Purpose | Terminal Post | -40 C | 100 °C | ||
TE Connectivity AMP Connectors | CE CSA ENEC UKCA UR | 450 A | DC | 500 V | Chassis Mount | DC | Two Stage | General Purpose | Quick Connect Threaded Post (M10) | -40 C | 100 °C | |
 TE Connectivity AMP Connectors | CE CSA ENEC UKCA UR | 600 A | DC | 1000 V | Chassis Mount | DC | Two Stage | General Purpose | Quick Connect Threaded Post (M10) | -40 C | 100 °C | 1 kV |
 TE Connectivity AMP Connectors | CE CSA ENEC UKCA UR | 450 A | DC | 1000 V | Chassis Mount | DC | Two Stage | General Purpose | Quick Connect Threaded Post (M10) | -40 C | 100 °C | 1 kV |
