307-050 Series
Manufacturer: EDAC Inc.
Beta
⌘K
CONN EDGE DUAL FMALE 50POS 0.156
| Part | Material - Insulation | Termination Rows [custom] | Contact Material | Number of Positions | Operating Temperature [Min] | Operating Temperature [Max] | Flange Feature | Number of Rows [custom] | Color | Termination | Card Thickness [Max] | Card Thickness [Min] | Contact Finish | Card Type | Features | Pitch | Pitch | Read Out | Contact Type | Number of Positions/Bay/Row | Gender | Mounting Type | Flange Feature [diameter] | Flange Feature [diameter] | Contact Finish Thickness | Contact Finish Thickness |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 EDAC Inc. | Polyester Thermoplastic | 2 | Copper Alloy | 50 | -40 C | 105 ░C | 4-40 Flush Mount Threaded Insert Top Opening | 2 | Green | Solder | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Tin | Non Specified - Dual Edge | Card Guides | 3.96 mm | 0.156 in | Dual | Semi Bellows | 25 | Female | Board Edge Straddle Mount | ||||
 EDAC Inc. | Polyester Thermoplastic | 2 | Copper Alloy | 50 | -40 C | 105 ░C | Flush Mount Top Opening Unthreaded | 2 | Green | Wire Wrap | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Tin | Non Specified - Dual Edge | 3.96 mm | 0.156 in | Dual | Semi Bellows | 25 | Female | Through Hole | 0.156 " | 3.96 mm | |||
 EDAC Inc. | Polyester Thermoplastic | 2 | Copper Alloy | 50 | -40 C | 105 ░C | 4-40 Flush Mount Threaded Insert Top Opening | 2 | Green | Solder | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Gold | Non Specified - Dual Edge | Card Guides | 3.96 mm | 0.156 in | Dual | Semi Bellows | 25 | Female | Through Hole | 0.25 Ám | 10 Áin | ||
 EDAC Inc. | Polyester Thermoplastic | 2 | Copper Alloy | 50 | -40 C | 105 ░C | 2 | Green | Solder Eyelet(s) | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Tin | Non Specified - Dual Edge | 3.96 mm | 0.156 in | Dual | Semi Bellows | 25 | Female | Through Hole | ||||||
 EDAC Inc. | Polyester Thermoplastic | 2 | Copper Alloy | 50 | -40 C | 105 ░C | Floating Bobbin Flush Mount | 2 | Green | Solder | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Tin | Non Specified - Dual Edge | 3.96 mm | 0.156 in | Dual | Semi Bellows | 25 | Female | Board Edge Straddle Mount | 0.116 " | 2.95 mm | |||
 EDAC Inc. | Polyester Thermoplastic | 2 | Copper Alloy | 50 | -40 C | 105 ░C | 4-40 Flush Mount Threaded Insert Top Opening | 2 | Green | Solder | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Tin | Non Specified - Dual Edge | Card Guides | 3.96 mm | 0.156 in | Dual | Semi Bellows | 25 | Female | Right Angle Through Hole | ||||
 EDAC Inc. | Polyester Thermoplastic | 2 | Copper Alloy | 50 | -40 C | 105 ░C | 4-40 Flush Mount Threaded Insert Top Opening | 2 | Green | Solder | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Gold | Non Specified - Dual Edge | Card Guides | 3.96 mm | 0.156 in | Dual | Semi Bellows | 25 | Female | Through Hole | 0.25 Ám | 10 Áin | ||
 EDAC Inc. | Polyester Thermoplastic | 2 | Copper Alloy | 50 | -40 C | 105 ░C | 2 | Green | Wire Wrap | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Tin | Non Specified - Dual Edge | 3.96 mm | 0.156 in | Dual | Semi Bellows | 25 | Female | Through Hole | ||||||
 EDAC Inc. | Polyester Thermoplastic | 2 | Copper Alloy | 50 | -40 C | 105 ░C | Floating Bobbin Flush Mount | 2 | Green | Solder | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Tin | Non Specified - Dual Edge | 3.96 mm | 0.156 in | Dual | Semi Bellows | 25 | Female | Through Hole | 0.116 " | 2.95 mm | |||
 EDAC Inc. | Polyester Thermoplastic | 2 | Copper Alloy | 50 | -40 C | 105 ░C | Flush Mount M3 Threaded Insert Top Opening | 2 | Green | Solder Eyelet(s) | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Gold | Non Specified - Dual Edge | Card Extender | 3.96 mm | 0.156 in | Dual | Semi Bellows | 25 | Female | Board Edge Straddle Mount | 0.25 Ám | 10 Áin |
