DDR-60 Series

Catalog

DC/DC DIN RAIL SUPPLY 15V 60W

Part	Power (Watts)	Applications	Approval Agency	Voltage - Output 1	Features	Size / Dimension [y]	Size / Dimension [z]	Size / Dimension [x]	Size / Dimension [z]	Size / Dimension [x]	Size / Dimension [y]	Current - Output (Max) [Max]	DC Voltage - Input (Max) [Max]	Number of Outputs	Voltage - Isolation	Efficiency	Input Type	DC Voltage - Input (Min) [Min]	Operating Temperature [Min]	Operating Temperature [Max]	Current - Output (Max)
MEAN WELL USA Inc. DDR-60L-15	60 W	ITE (Commercial)	CE EAC	15 V	Adjustable Output	52.5 mm	3.54 "	54.5 mm	90 mm	2.15 "	2.07 in	4 A	75 V	1	4000 V	92 %	DC	18 V	-40 °C	85 °C
MEAN WELL USA Inc. DDR-60G-12	60 W	ITE (Commercial)	CE EAC	12 V	Adjustable Output	52.5 mm	3.54 "	54.5 mm	90 mm	2.15 "	2.07 in		36 V	1	4000 V	91 %	DC	9 V	-40 °C	85 °C	5 A
MEAN WELL USA Inc. DDR-60G-5	54 W	ITE (Commercial)	CE EAC	5 V	Adjustable Output	52.5 mm	3.54 "	54.5 mm	90 mm	2.15 "	2.07 in	10.8 A	36 V	1	4000 V	87.5 %	DC	9 V	-40 °C	85 °C
MEAN WELL USA Inc. DDR-60G-24	60 W	ITE (Commercial)	CE EAC	24 V	Adjustable Output	52.5 mm	3.54 "	54.5 mm	90 mm	2.15 "	2.07 in	2.5 A	36 V	1	4000 V	91 %	DC	9 V	-40 °C	85 °C
MEAN WELL USA Inc. DDR-60L-24	60 W	ITE (Commercial)	CE EAC	24 V	Adjustable Output	52.5 mm	3.54 "	54.5 mm	90 mm	2.15 "	2.07 in	2.5 A	75 V	1	4000 V	92 %	DC	18 V	-40 °C	85 °C
MEAN WELL USA Inc. DDR-60G-15	60 W	ITE (Commercial)	CE EAC	15 V	Adjustable Output	52.5 mm	3.54 "	54.5 mm	90 mm	2.15 "	2.07 in	4 A	36 V	1	4000 V	91 %	DC	9 V	-40 °C	85 °C
