RXG Series
Manufacturer: SCHNEIDER ELECTRIC
Beta
⌘K
INDUSTRIAL RELAYS RXG RELAY & SOCKET,1C/O 10A 24VAC, VARISTOR
| Part | Relay Type | Must Release Voltage | Load - Max Switching [Max] | Mounting Type | Termination Style | Contact Material | Release Time | Switching Voltage [Max] | Coil Insulation | Coil Type | Approval Agency | Operate Time | Contact Rating (Current) | Contact Form | Coil Voltage | Operating Temperature [Max] | Operating Temperature [Min] | Features | Load - Max Switching | Coil Current | Must Operate Voltage |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 SCHNEIDER ELECTRIC | General Purpose | 7.2 VAC | 2500 VA | Socketable | Plug In | Silver Alloy | 20 ms | 250 VAC | Class F | Non Latching | CE CSA DNV-GL EAC UL | 20 ms | 10 A | SPDT (1 Form C) | 24 VAC | 70 °C | -40 C | Lighted Indicator Test Button | |||
 SCHNEIDER ELECTRIC | General Purpose | 7.2 VAC | Socketable | Plug In | Silver Tin Oxide Indium Oxide (AgSnOInO) | 20 ms | 30 VDC 250 VAC | Non Latching | CE CSA DNV-GL EAC UL | 20 ms | 5 A | DPDT (2 Form C) | 24 VAC | 70 °C | -40 C | Lighted Indicator | 150 W 1250 VA | ||||
 SCHNEIDER ELECTRIC | General Purpose | 7.2 VAC | Socketable | Plug In | Silver Tin Oxide Indium Oxide (AgSnOInO) | 20 ms | 30 VDC 250 VAC | Non Latching | CE CSA DNV-GL EAC UL | 20 ms | 5 A | DPDT (2 Form C) | 24 VAC | 70 °C | -40 C | 150 W 1250 VA | |||||
 SCHNEIDER ELECTRIC | General Purpose | 36 VAC | Socketable | Plug In | Silver Tin Oxide Indium Oxide (AgSnOInO) | 20 ms | 30 VDC 250 VAC | Non Latching | CE CSA DNV-GL EAC UL | 20 ms | 5 A | DPDT (2 Form C) | 120 VAC | 70 °C | -40 C | Lighted Indicator | 150 W 1250 VA | ||||
 SCHNEIDER ELECTRIC | General Purpose | 14.4 VAC | Socketable | Plug In | Silver Tin Oxide Indium Oxide (AgSnOInO) | 20 ms | 30 VDC 250 VAC | Class F | Non Latching | CE CSA DNV-GL EAC UL | 20 ms | 10 A | SPDT (1 Form C) | 48 VAC | 70 °C | -40 C | Lighted Indicator Test Button | 300 W 2500 VA | 43.6 mA | 38.4 VAC | |
SCHNEIDER ELECTRIC | General Purpose | 7.2 VAC | Socketable | Plug In | Silver Tin Oxide Indium Oxide (AgSnOInO) | 20 ms | 30 VDC 250 VAC | Non Latching | CE CSA DNV-GL EAC UL | 20 ms | 10 A | SPDT (1 Form C) | 24 VAC | 70 °C | -40 C | Lighted Indicator | 300 W 2500 VA | 19.2 VAC | |||
 SCHNEIDER ELECTRIC | General Purpose | 7.2 VAC | Socketable | Plug In | Silver Alloy | 20 ms | 250 VAC | Class F | Non Latching | CE CSA DNV-GL EAC UL | 20 ms | 5 A | DPDT (2 Form C) | 24 VAC | 70 °C | -40 C | Lighted Indicator Test Button | 1250 VA | |||
 SCHNEIDER ELECTRIC | General Purpose | 2.4 VDC | Socketable | Plug In | Silver Tin Oxide Indium Oxide (AgSnOInO) | 20 ms | 30 VDC 250 VAC | Non Latching | CE CSA DNV-GL EAC UL | 20 ms | 10 A | SPDT (1 Form C) | 24 VDC | 70 °C | -40 C | Lighted Indicator Test Button | 300 W 2500 VA | ||||
 SCHNEIDER ELECTRIC | General Purpose | 1.2 VDC | Socketable | Plug In | Silver Tin Oxide Indium Oxide (AgSnOInO) | 20 ms | 30 VDC 250 VAC | Non Latching | CE CSA DNV-GL EAC UL | 20 ms | 10 A | SPDT (1 Form C) | 12 VDC | 70 °C | -40 C | 300 W 2500 VA | |||||
 SCHNEIDER ELECTRIC | General Purpose | 69 VAC | Socketable | Plug In | Silver Alloy | 20 ms | 250 VAC | Class F | Non Latching | CE CSA DNV-GL EAC UL | 20 ms | 5 A | DPDT (2 Form C) | 230 VAC | 70 °C | -45 °C | Lighted Indicator | 1250 VA |
