W4E350 Series
Manufacturer: ebm-papst Inc.
Beta
⌘K
FAN AXIAL
| Part | Current Rating (Amps) | Material - Blade | Material - Frame | Bearing Type | Termination | Voltage - Rated | Operating Temperature [Max] | Operating Temperature [Min] | Operating Temperature [Min] | Operating Temperature [Max] | RPM | Width [y] | Fan Type | Ingress Protection | Power (Watts) | Features | Approval Agency | Static Pressure | Static Pressure | Size / Dimension | Size / Dimension [diameter] | Material - Blade [custom] | Material - Blade [custom] | Size / Dimension [z] | Size / Dimension [x] | Width [x] |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 ebm-papst Inc. | 1.8 A | Polypropylene (PP) | Plastic Coating Steel | Ball | 4 Wire Leads with Splice Terminals | 115 VAC | 40 °C | -25 °C | -25 °C | 40 °C | 1390 RPM | 132.3 mm | Tubeaxial | IP44 | 215 W | Capacitor Thermal Overload Protector (TOP) | CE CSA UL | 55 Pa | 0.22 in H2O | Round | 460 mm | |||||
 ebm-papst Inc. | 910 mA | Plastic Coating Steel | Ball | 4 Wire Leads with Splice Terminals | 230 VAC | 132.3 mm | Tubeaxial | IP44 | 215 W | Capacitor Thermal Overload Protector (TOP) | CSA UL | 60 Pa | 0.241 in H2O | Round | 460 mm | Polypropylene (PP) Coating | Steel | |||||||||
 ebm-papst Inc. | 1.68 A | Steel | Plastic Coating Steel | Ball | 4 Wire Leads with Splice Terminals | 115 VAC | 25 °C | -25 °C | -25 °C | 25 °C | 1540 RPM | Tubeaxial | IP44 | 193 W | Capacitor Thermal Overload Protector (TOP) | CSA UL | 90.5 Pa | 0.363 in H2O | 485 mm | 485 mm | 95 mm |
