895-013 Series
Manufacturer: EDAC Inc.
Beta
⌘K
CONN EDGE SINGLE FML 13POS 0.100
| Part | Termination Rows | Material - Insulation | Card Type | Number of Positions/Bay/Row | Number of Positions | Read Out | Gender | Operating Temperature [Max] | Operating Temperature [Min] | Contact Finish | Color | Number of Rows | Mounting Type | Card Thickness [Max] | Card Thickness [Min] | Flange Feature | Flange Feature [diameter] | Flange Feature [diameter] | Pitch | Pitch | Contact Material | Contact Type | Contact Finish Thickness | Contact Finish Thickness | Termination |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 EDAC Inc. | 1 | Polyphenylene Sulfide (PPS) | Non Specified - Single Edge | 13 | 13 | Single | Female | 125 °C | -40 C | Gold | Black | 1 | Through Hole | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Floating Bobbin Top Mount Opening | 0.116 " | 2.95 mm | 0.1 " | 2.54 mm | Copper Alloy | Cantilever | 0.25 Ám | 10 Áin | Solder |
 EDAC Inc. | 1 | Polyphenylene Sulfide (PPS) | Non Specified - Single Edge | 13 | 13 | Single | Female | 125 °C | -40 C | Gold | Black | 1 | Through Hole | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 0.128 " | 3.25 mm | 0.1 " | 2.54 mm | Copper Alloy | Cantilever | 0.25 Ám | 10 Áin | Solder | |
 EDAC Inc. | 1 | Polyphenylene Sulfide (PPS) | Non Specified - Single Edge | 13 | 13 | Single | Female | 125 °C | -40 C | Gold | Black | 1 | Right Angle Through Hole | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Floating Bobbin Top Mount Opening | 0.116 " | 2.95 mm | 0.1 " | 2.54 mm | Copper Alloy | Cantilever | 0.25 Ám | 10 Áin | Solder |
 EDAC Inc. | 1 | Polyphenylene Sulfide (PPS) | Non Specified - Single Edge | 13 | 13 | Single | Female | 125 °C | -40 C | Gold | Black | 1 | Through Hole | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 0.156 " | 3.96 mm | 0.1 " | 2.54 mm | Copper Alloy | Cantilever | 0.25 Ám | 10 Áin | Wire Wrap | |
 EDAC Inc. | 1 | Polyphenylene Sulfide (PPS) | Non Specified - Single Edge | 13 | 13 | Single | Female | 125 °C | -40 C | Gold | Black | 1 | Through Hole | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 4-40 Threaded Insert Top Mount Opening | 0.1 " | 2.54 mm | Copper Alloy | Cantilever | 0.25 Ám | 10 Áin | Solder | ||
 EDAC Inc. | 1 | Polyphenylene Sulfide (PPS) | Non Specified - Single Edge | 13 | 13 | Single | Female | 125 °C | -40 C | Gold | Black | 1 | Through Hole | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Side Mount Opening Unthreaded | 0.128 " | 3.25 mm | 0.1 " | 2.54 mm | Copper Alloy | Cantilever | 0.25 Ám | 10 Áin | Solder |
 EDAC Inc. | 1 | Polyphenylene Sulfide (PPS) | Non Specified - Single Edge | 13 | 13 | Single | Female | 125 °C | -40 C | Gold | Black | 1 | Through Hole | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Flush Mount Side Opening Unthreaded | 0.128 " | 3.25 mm | 0.1 " | 2.54 mm | Copper Alloy | Cantilever | 0.25 Ám | 10 Áin | Wire Wrap |
 EDAC Inc. | 1 | Polyphenylene Sulfide (PPS) | Non Specified - Single Edge | 13 | 13 | Single | Female | 125 °C | -40 C | Gold | Black | 1 | Right Angle Through Hole | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 0.156 " | 3.96 mm | 0.1 " | 2.54 mm | Copper Alloy | Cantilever | 0.25 Ám | 10 Áin | Solder | |
 EDAC Inc. | 1 | Polyphenylene Sulfide (PPS) | Non Specified - Single Edge | 13 | 13 | Single | Female | 125 °C | -40 C | Gold | Black | 1 | Through Hole | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 4-40 Threaded Insert Top Mount Opening | 0.1 " | 2.54 mm | Copper Alloy | Cantilever | 0.25 Ám | 10 Áin | Solder | ||
 EDAC Inc. | 1 | Polyphenylene Sulfide (PPS) | Non Specified - Single Edge | 13 | 13 | Single | Female | 125 °C | -40 C | Gold | Black | 1 | Through Hole | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 0.156 " | 3.96 mm | 0.1 " | 2.54 mm | Copper Alloy | Cantilever | 0.25 Ám | 10 Áin | Wire Wrap |
