RP202 Series

Catalog

IC REG LIN 2.95V 200MA DFN1010-4

Part	PSRR	Current - Quiescent (Iq)	Control Features	Protection Features	Voltage - Input (Max) [Max]	Current - Output	Package / Case	Operating Temperature [Max]	Operating Temperature [Min]	Number of Regulators	Supplier Device Package	Output Configuration	Mounting Type	Voltage - Output (Min/Fixed) [Min]	Voltage Dropout (Max) [Max]	Voltage - Output (Min/Fixed)	Voltage Dropout (Max)
Nisshinbo Micro Devices Inc. RP202K291D5-TR	65 dB	5 µA	Enable	Over Current	5.25 V	0.2 A	4-UDFN Exposed Pad	85 C	-40 ¯C	1	DFN(PL)1010-4	Positive	Surface Mount	2.95 V	0.29 V
Nisshinbo Micro Devices Inc. RP202K281D5-TR	65 dB	5 µA	Enable	Over Current	5.25 V	0.2 A	4-UDFN Exposed Pad	85 C	-40 ¯C	1	DFN(PL)1010-4	Positive	Surface Mount		0.29 V	2.85 V
Nisshinbo Micro Devices Inc. RP202K111D-TR	75 dB	5 µA	Enable	Over Current	5.25 V	0.2 A	4-UDFN Exposed Pad	85 C	-40 ¯C	1	DFN(PL)1010-4	Positive	Surface Mount			1.1 V	0.61 V
Nisshinbo Micro Devices Inc. RP202K301B-TR	65 dB	5 µA	Enable	Over Current	5.25 V	0.2 A	4-UDFN Exposed Pad	85 C	-40 ¯C	1	DFN(PL)1010-4	Positive	Surface Mount			3 V	0.28 V
