68461 Series

Catalog

BERGSTIK II .100CC DR ST RAIGHT

Part	Contact Length - Post [x]	Contact Length - Post [x]	Connector Type	Contact Finish Thickness - Mating	Contact Finish Thickness - Mating	Contact Shape	Voltage Rating	Shrouding	Pitch - Mating	Pitch - Mating	Mounting Type	Termination	Number of Rows	Number of Positions	Fastening Type	Contact Type	Number of Positions Loaded	Contact Material	Contact Finish - Post	Current Rating (Amps)	Insulation Height [z]	Insulation Height [z]	Material Flammability Rating	Insulation Color	Contact Length - Mating	Contact Length - Mating	Number of Positions	Contact Finish - Mating
Amphenol ICC (FCI) 68461-410HLF	0.32 in	8.13 mm	Header	2.54 çm	100 çin	Square	110 VDC	Unshrouded	0.1 in	2.54 mm	Through Hole Right Angle	Solder	1	10	Push-Pull	Male Pin	All	Phosphor Bronze	Tin	5 A	0.095 in	2.41 mm	UL94 V-0	Black	10.16 mm	0.4 in
Amphenol ICC (FCI) 68461-430HLF	0.32 in	8.13 mm	Header	2.54 çm	100 çin	Square	110 VDC	Unshrouded	0.1 in	2.54 mm	Through Hole Right Angle	Solder	1	30	Push-Pull	Male Pin	All	Phosphor Bronze	Tin	5 A	0.095 in	2.41 mm	UL94 V-0	Black	10.16 mm	0.4 in
Amphenol ICC (FCI) 68461-420HLF	0.32 in	8.13 mm	Header	2.54 çm	100 çin	Square	110 VDC	Unshrouded	0.1 in	2.54 mm	Through Hole Right Angle	Solder	1	20	Push-Pull	Male Pin	All	Phosphor Bronze	Tin	5 A	0.095 in	2.41 mm	UL94 V-0	Black	10.16 mm	0.4 in
Amphenol ICC (FCI) 68461-416HLF	0.32 in	8.13 mm	Header	2.54 çm	100 çin	Square	110 VDC	Unshrouded	0.1 in	2.54 mm	Through Hole Right Angle	Solder	1		Push-Pull	Male Pin	All	Phosphor Bronze	Tin	5 A	0.095 in	2.41 mm	UL94 V-0	Black	10.16 mm	0.4 in	16
Amphenol ICC (FCI) 68461-422HLF	0.32 in	8.13 mm	Header	2.54 çm	100 çin	Square	110 VDC	Unshrouded	0.1 in	2.54 mm	Through Hole Right Angle	Solder	1	22 positions	Push-Pull	Male Pin	All	Phosphor Bronze	Tin	5 A	0.095 in	2.41 mm	UL94 V-0	Black	10.16 mm	0.4 in
Amphenol ICC (FCI) 68461-236HLF	0.32 in	8.13 mm	Header	0.38 µm	15 µin	Square	110 VDC	Unshrouded	0.1 in	2.54 mm	Through Hole Right Angle	Solder	1	36	Push-Pull	Male Pin	All	Phosphor Bronze		5 A	0.095 in	2.41 mm	UL94 V-0	Black	10.16 mm	0.4 in		Gold or Gold GXT™
Amphenol ICC (FCI) 68461-407HLF	0.32 in	8.13 mm	Header	2.54 çm	100 çin	Square	110 VDC	Unshrouded	0.1 in	2.54 mm	Through Hole Right Angle	Solder	1	4	Push-Pull	Male Pin	All	Phosphor Bronze	Tin	5 A	0.095 in	2.41 mm	UL94 V-0	Black	10.16 mm	0.4 in
Amphenol ICC (FCI) 68461-106HLF	0.32 in	8.13 mm	Header	0.76 Ám	30 Áin	Square	110 VDC	Unshrouded	0.1 in	2.54 mm	Through Hole Right Angle	Solder	1	6	Push-Pull	Male Pin	All	Phosphor Bronze		5 A	0.095 in	2.41 mm	UL94 V-0	Black	10.16 mm	0.4 in		Gold or Gold GXT™
Amphenol ICC (FCI) 68461-119HLF	0.32 in	8.13 mm	Header	0.76 Ám	30 Áin	Square	110 VDC	Unshrouded	0.1 in	2.54 mm	Through Hole Right Angle	Solder	1	19	Push-Pull	Male Pin	All	Phosphor Bronze		5 A	0.095 in	2.41 mm	UL94 V-0	Black	10.16 mm	0.4 in		Gold or Gold GXT™
Amphenol ICC (FCI) 68461-113HLF	0.32 in	8.13 mm	Header	0.76 Ám	30 Áin	Square	110 VDC	Unshrouded	0.1 in	2.54 mm	Through Hole Right Angle	Solder	1	13	Push-Pull	Male Pin	All	Phosphor Bronze		5 A	0.095 in	2.41 mm	UL94 V-0	Black	10.16 mm	0.4 in		Gold or Gold GXT™
