51763 Series
Manufacturer: Amphenol ICC (FCI)
Beta
⌘K
CONN RCPT BLADE PWR 6POS EDGE MT
| Part | Connector Type | Material Flammability Rating | Color | Connector Style | Number of Rows | Termination | Mounting Type | Operating Temperature [Min] | Operating Temperature [Max] | Contact Finish | Number of Positions | Contact Layout, Typical | Contact Finish Thickness | Contact Finish Thickness | Number of Positions Loaded | Features |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
Amphenol ICC (FCI) | Receptacle Female Blade Sockets | UL94 V-0 | Black | Blade Power | 1 | Press-Fit | Board Edge Right Angle Through Hole | -20 C | 105 ░C | Gold | 6 | 6 Power | 0.76 Ám | 30 Áin | All | Board Lock Guide Pin |
Amphenol ICC (FCI) | Receptacle Female Blade Sockets | UL94 V-0 | Black | Blade Power | 1 | Solder | Board Edge Right Angle Through Hole | -20 C | 105 ░C | Gold | 4 | 4 Power | 0.76 Ám | 30 Áin | All | Board Lock Guide Pin |
 Amphenol ICC (FCI) | Receptacle Female Blade Sockets | UL94 V-0 | Black | Blade Power | 1 | Solder | Board Edge Right Angle Through Hole | -20 C | 105 ░C | Gold | 8 | 8 Power | 0.76 Ám | 30 Áin | All | Board Lock Guide Pin |
Amphenol ICC (FCI) | Receptacle Female Blade Sockets | UL94 V-0 | Black | Blade Power | 1 | Solder | Board Edge Right Angle Through Hole | -20 C | 105 ░C | Gold | 5 Power | 0.76 Ám | 30 Áin | All | Board Lock Guide Pin | |
Amphenol ICC (FCI) | Receptacle Female Blade Sockets | UL94 V-0 | Black | Blade Power | 1 | Solder | Board Edge Right Angle Through Hole | -20 C | 105 ░C | Gold | 3 Power | 0.76 Ám | 30 Áin | All | Board Lock Guide Pin | |
Amphenol ICC (FCI) | Receptacle Female Blade Sockets | UL94 V-0 | Black | Blade Power | 1 | Solder | Board Edge Right Angle Through Hole | -20 C | 105 ░C | Gold | 8 | 8 Power | 0.76 Ám | 30 Áin | All | Guide Pin |
Amphenol ICC (FCI) | Receptacle Female Blade Sockets | UL94 V-0 | Black | Blade Power | 1 | Solder | Board Edge Right Angle Through Hole | -20 C | 105 ░C | Gold | 2 | 2 Power | 0.76 Ám | 30 Áin | All | Board Lock Guide Pin |
Amphenol ICC (FCI) | Receptacle Female Blade Sockets | UL94 V-0 | Black | Blade Power | 1 | Press-Fit | Board Edge Right Angle Through Hole | -20 C | 105 ░C | Gold | 8 | 8 Power | 0.76 Ám | 30 Áin | All | Guide Pin |
Amphenol ICC (FCI) | Receptacle Female Blade Sockets | UL94 V-0 | Black | Blade Power | 1 | Press-Fit | Board Edge Right Angle Through Hole | -20 C | 105 ░C | Gold | 6 | 6 Power | 0.76 Ám | 30 Áin | All | Guide Pin |
