SCHRACK Low Power PCB Relays Series
Manufacturer: TE Connectivity AMP Connectors
Beta
⌘K
GENERAL PURPOSE RELAYS 8A, 48VDC 1 FORM C(CO) PCB MNT
| Part | Seal Rating | Coil Current | Relay Type | Coil Type | Mounting Type | Operating Temperature [Max] | Operating Temperature [Min] | Approval Agency | Termination Style | Load - Max Switching | Contact Material | Must Release Voltage | Release Time | Contact Rating (Current) | Switching Voltage [Max] | Coil Voltage | Operate Time | Contact Form | Must Operate Voltage | Coil Resistance | Load - Max Switching [Max] | Coil Insulation |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 TE Connectivity AMP Connectors | Sealed - Fully | 5.5 mA | General Purpose | Non Latching | Through Hole | 85 °C | -40 C | cURus VDE | PC Pin | 3200 VA | Silver Tin Oxide (AgSnO) | 4.8 VDC | 5 ms | 8 A | 400 VAC | 48 VDC | 10 ms | SPDT (1 Form C) | ||||
 TE Connectivity AMP Connectors | Sealed - Fully | 5.5 mA | General Purpose | Non Latching | Through Hole | 85 °C | -40 C | cURus VDE | PC Pin | 3200 VA | Silver Tin Oxide (AgSnO) | 4.8 VDC | 5 ms | 8 A | 400 VAC | 48 VDC | 10 ms | SPST-NO (1 Form A) | ||||
 TE Connectivity AMP Connectors | Sealed - Fully | 36.3 mA | General Purpose | Non Latching | Through Hole | 85 °C | -40 C | cURus VDE | PC Pin | 3200 VA | Silver Tin Oxide (AgSnO) | 0.6 VDC | 5 ms | 8 A | 400 VAC | 10 ms | SPST-NO (1 Form A) | 4.1 VDC | ||||
 TE Connectivity AMP Connectors | Sealed - Fully | 0.075 A | General Purpose | Non Latching | Through Hole | 85 °C | -40 C | cURus VDE | PC Pin | 3200 VA | Silver Tin Oxide (AgSnO) | 0.3 VDC | 5 ms | 8 A | 400 VAC | 10 ms | SPST-NO (1 Form A) | 2.1 VDC | ||||
 TE Connectivity AMP Connectors | Sealed - Fully | 36.3 mA | General Purpose | Non Latching | Through Hole | 85 °C | -40 C | cURus VDE | PC Pin | 3200 VA | Silver Tin Oxide (AgSnO) | 0.6 VDC | 5 ms | 8 A | 400 VAC | 10 ms | SPDT (1 Form C) | 4.1 VDC | ||||
 TE Connectivity AMP Connectors | Sealed - Fully | 10.6 mA | General Purpose | Non Latching | Through Hole | 85 °C | -40 C | cURus VDE | PC Pin | 3200 VA | Silver Tin Oxide (AgSnO) | 2.4 VDC | 5 ms | 8 A | 400 VAC | 24 VDC | 10 ms | SPDT (1 Form C) | 16.3 VDC | 2.27 kOhms | 2000 VA | |
 TE Connectivity AMP Connectors | 18.4 mA | General Purpose | Non Latching | Through Hole | 85 °C | -40 C | cURus VDE | PC Pin | 3200 VA | Silver Tin Oxide (AgSnO) | 1.2 VDC | 5 ms | 10 A | 400 VAC | 12 VDC | 10 ms | SPDT (1 Form C) | 8.2 VDC | Class F | |||
 TE Connectivity AMP Connectors | Sealed - Flux Protection | 18.4 mA | General Purpose | Non Latching | Through Hole | 85 °C | -40 C | cURus VDE | PC Pin | 3200 VA | Silver Tin Oxide (AgSnO) | 1.2 VDC | 5 ms | 10 A | 400 VAC | 12 VDC | 10 ms | SPDT (1 Form C) | 8.2 VDC | 2000 VA | Class F | |
 TE Connectivity AMP Connectors | Sealed - Flux Protection | 10.6 mA | General Purpose | Non Latching | Through Hole | 85 °C | -40 C | cURus VDE | PC Pin | Silver Tin Oxide (AgSnO) | 2.4 VDC | 5 ms | 10 A | 400 VAC | 24 VDC | 10 ms | SPDT (1 Form C) | 16.3 VDC | 4000 VA | Class F | ||
 TE Connectivity AMP Connectors | Sealed - Fully | 4 mA | General Purpose | Non Latching | Through Hole | 85 °C | -40 C | cURus VDE | PC Pin | 3200 VA | Silver Tin Oxide (AgSnO) | 6 VDC | 5 ms | 8 A | 400 VAC | 60 VDC | 10 ms | SPDT (1 Form C) | 40.8 VDC | 15.27 kOhms |
