ec3a Series

Manufacturer: Cincon Electronics Co. LTD

Catalog

CONVERTER: DC/DC; 3W; UIN: 36÷72VDC; UOUT: 5VDC; 5V; UOUT2: -5VDC

Part	Size / Dimension [y]	Size / Dimension [z]	Size / Dimension [x]	Size / Dimension [z]	Size / Dimension [y]	Size / Dimension [x]	Voltage - Isolation	Voltage - Input (Max) [Max]	Voltage - Input (Min) [Min]	Mounting Type	Operating Temperature [Max]	Operating Temperature [Min]	Number of Outputs	Applications	Standard Number	Voltage - Output 1	Current - Output (Max) [Max]	Efficiency	Type	Voltage - Output 2	Features	Package / Case	Approval Agency	Power (Watts)	Current - Output (Max)	Current - Output (Max)
Cincon Electronics Co. LTD EC3A34HM	0.8 "	0.4 "	31.8 mm	10.2 mm	20.3 mm	1.25 in	1.5 kV	72 V	36 V	Through Hole	71 °C	-25 °C	2	ITE (Commercial)	60950-1	5 V	0.3 A	78 %	Isolated Module	-5 V	SCP	24-DIP Module 14 Leads	CE cURus	3 W
Cincon Electronics Co. LTD EC3A32HM	0.8 "	0.4 "	31.8 mm	10.2 mm	20.3 mm	1.25 in	1.5 kV	72 V	36 V	Through Hole	71 °C	-25 °C	1	ITE (Commercial)	60950-1	12 V	250 mA	80 %	Isolated Module		SCP	24-DIP Module 14 Leads	CE cURus	3 W
Cincon Electronics Co. LTD EC3A16HM	0.8 "	0.4 "	31.8 mm	10.2 mm	20.3 mm	1.25 in	1.5 kV	18 V	9 V	Through Hole	71 °C	-25 °C	2	ITE (Commercial)	60950-1	15 V		79 %	Isolated Module	-15 V	SCP	24-DIP Module 14 Leads	CE cURus	3 W	100 mA	100 mA
Cincon Electronics Co. LTD EC3A24HM	0.8 "	0.4 "	31.8 mm	10.2 mm	20.3 mm	1.25 in	1.5 kV	36 V	18 V	Through Hole	71 °C	-25 °C	2	ITE (Commercial)	60950-1	5 V	0.3 A	77 %	Isolated Module	-5 V	SCP	24-DIP Module 14 Leads	CE cURus	3 W
Cincon Electronics Co. LTD EC3A32H	0.8 "	0.4 "	31.8 mm	10.2 mm	20.3 mm	1.25 in	3000 V	72 V	36 V	Through Hole	71 °C	-25 °C	1	ITE (Commercial)	60950-1	12 V	250 mA	80 %	Isolated Module		SCP	24-DIP Module 14 Leads	CE cURus	3 W
Cincon Electronics Co. LTD EC3A31H	0.8 "	0.4 "	31.8 mm	10.2 mm	20.3 mm	1.25 in	3000 V	72 V	36 V	Through Hole	71 °C	-25 °C	1	ITE (Commercial)	60950-1	5 V	600 mA	79 %	Isolated Module		SCP	24-DIP Module 14 Leads	CE cURus	3 W
Cincon Electronics Co. LTD EC3A36HM	0.8 "	0.4 "	31.8 mm	10.2 mm	20.3 mm	1.25 in	1.5 kV	72 V	36 V	Through Hole	71 °C	-25 °C	2	ITE (Commercial)	60950-1	15 V		78 %	Isolated Module	-15 V	SCP	24-DIP Module 14 Leads	CE cURus	3 W	100 mA	100 mA
Cincon Electronics Co. LTD EC3A17H	0.8 "	0.4 "	31.8 mm	10.2 mm	20.3 mm	1.25 in	3000 V	18 V	9 V	Through Hole	71 °C	-25 °C	1	ITE (Commercial)	60950-1	3.3 V	600 mA	72 %	Isolated Module		SCP	24-DIP Module 14 Leads	CE cURus	2 W
Cincon Electronics Co. LTD EC3A03H	0.8 "	0.4 "	31.8 mm	10.2 mm	20.3 mm	1.25 in	3000 V	6 V	4.5 V	Through Hole	71 °C	-25 °C	1	ITE (Commercial)	60950-1	15 V	200 mA	77 %	Isolated Module		SCP	24-DIP Module 14 Leads	CE cURus	3 W
Cincon Electronics Co. LTD EC3A36H	0.8 "	0.4 "	31.8 mm	10.2 mm	20.3 mm	1.25 in	3000 V	72 V	36 V	Through Hole	71 °C	-25 °C	2	ITE (Commercial)	60950-1	15 V		78 %	Isolated Module	-15 V	SCP	24-DIP Module 14 Leads	CE cURus	3 W	100 mA	100 mA
