833-020 Series
Manufacturer: EDAC Inc.
Beta
⌘K
CONN EDGE DUAL FMALE 20POS 0.156
| Part | Material - Insulation | Termination Rows [custom] | Contact Material | Contact Finish Thickness | Contact Finish Thickness | Gender | Number of Rows [custom] | Pitch | Pitch | Mounting Type | Number of Positions/Bay/Row | Operating Temperature [Max] | Operating Temperature [Min] | Contact Type | Card Type | Read Out | Contact Finish | Color | Number of Positions | Termination | Flange Feature | Flange Feature [diameter] | Flange Feature [diameter] | Card Thickness [Max] | Card Thickness [Min] | Termination Rows | Number of Rows | Features |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 EDAC Inc. | Diallyl Phthalate (DAP) | 2 | Copper Alloy | 0.25 Ám | 10 Áin | Female | 2 | 3.96 mm | 0.156 in | Through Hole | 10 | 125 °C | -40 C | Cantilever | Non Specified - Dual Edge | Dual | Gold | Green | 20 | Solder Eyelet(s) | Side Mount Opening Unthreaded | 0.128 " | 3.25 mm | 0.07 in 1.78 mm | 0.054 in 1.37 mm | |||
 EDAC Inc. | Diallyl Phthalate (DAP) | Copper Alloy | 0.25 Ám | 10 Áin | Female | 3.96 mm | 0.156 in | Through Hole | 20 Bay/Row | 125 °C | -40 C | Cantilever | Non Specified - Single Edge | Single | Gold | Green | 20 | Solder Eyelet(s) | Floating Bobbin Flush Mount | 0.116 " | 2.95 mm | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 1 | 1 | |||
 EDAC Inc. | Diallyl Phthalate (DAP) | 2 | Copper Alloy | 0.25 Ám | 10 Áin | Female | 2 | 3.96 mm | 0.156 in | Through Hole | 10 | 125 °C | -40 C | Cantilever | Non Specified - Dual Edge | Dual | Gold | Green | 20 | Solder | 4-40 Flush Mount Threaded Insert Top Opening | 0.07 in 1.78 mm | 0.054 in 1.37 mm | |||||
 EDAC Inc. | Diallyl Phthalate (DAP) | Copper Alloy | 0.25 Ám | 10 Áin | Female | 3.96 mm | 0.156 in | Through Hole | 20 Bay/Row | 125 °C | -40 C | Cantilever | Non Specified - Single Edge | Single | Gold | Green | 20 | Solder Eyelet(s) | 4-40 Threaded Insert Top Mount Opening | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 1 | 1 | |||||
 EDAC Inc. | Diallyl Phthalate (DAP) | Copper Alloy | 0.25 Ám | 10 Áin | Female | 3.96 mm | 0.156 in | Through Hole | 20 Bay/Row | 125 °C | -40 C | Cantilever | Non Specified - Single Edge | Single | Gold | Green | 20 | Solder | Side Mount Opening Unthreaded | 0.128 " | 3.25 mm | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 1 | 1 | |||
 EDAC Inc. | Diallyl Phthalate (DAP) | Copper Alloy | 0.25 Ám | 10 Áin | Female | 3.96 mm | 0.156 in | Through Hole | 20 Bay/Row | 125 °C | -40 C | Cantilever | Non Specified - Single Edge | Single | Gold | Green | 20 | Solder | M3 Threaded Insert Top Mount Opening | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 1 | 1 | |||||
 EDAC Inc. | Diallyl Phthalate (DAP) | 2 | Copper Alloy | 0.25 Ám | 10 Áin | Female | 2 | 3.96 mm | 0.156 in | Board Edge Straddle Mount | 10 | 125 °C | -40 C | Cantilever | Non Specified - Dual Edge | Dual | Gold | Green | 20 | Solder | Flush Mount Top Opening Unthreaded | 0.156 " | 3.96 mm | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Card Extender | ||
 EDAC Inc. | Diallyl Phthalate (DAP) | 2 | Copper Alloy | 0.25 Ám | 10 Áin | Female | 2 | 3.96 mm | 0.156 in | Board Edge Straddle Mount | 10 | 125 °C | -40 C | Cantilever | Non Specified - Dual Edge | Dual | Gold | Green | 20 | Solder | 4-40 Threaded Insert Top Mount Opening | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Card Extender | ||||
 EDAC Inc. | Diallyl Phthalate (DAP) | 2 | Copper Alloy | 0.25 Ám | 10 Áin | Female | 2 | 3.96 mm | 0.156 in | Through Hole | 10 | 125 °C | -40 C | Cantilever | Non Specified - Dual Edge | Dual | Gold | Green | 20 | Solder | 0.156 " | 3.96 mm | 0.07 in 1.78 mm | 0.054 in 1.37 mm | ||||
 EDAC Inc. | Diallyl Phthalate (DAP) | 2 | Copper Alloy | 0.25 Ám | 10 Áin | Female | 2 | 3.96 mm | 0.156 in | Through Hole | 10 | 125 °C | -40 C | Cantilever | Non Specified - Dual Edge | Dual | Gold | Green | 20 | Wire Wrap | Floating Bobbin Flush Mount | 0.116 " | 2.95 mm | 0.07 in 1.78 mm | 0.054 in 1.37 mm |
