DC12.5202 Series
Manufacturer: SCHURTER Inc.
Beta
⌘K
PWR ENT MOD RCPT IEC320-C18 PNL
| Part | Filter Type | Connector Style | Features | Current Rating - Appliance Inlet | Voltage Rating - Appliance Inlet | Switch Features | Material Flammability Rating | Panel Cutout Dimensions [y] | Panel Cutout Dimensions [x] | Accomodates a Fuse | Panel Thickness [Max] | Panel Thickness [Max] | Panel Thickness [Min] | Panel Thickness [Min] | Approval Agency | Connector Type | Current Rating - Filter | Termination | Termination | Termination | Ingress Protection | Mounting Type | Number of Positions |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 SCHURTER Inc. | Filtered (EMI RFI) - Commercial Medical | IEC 320-C18 | Shielded V-Lock Notch | 10 A | 250 VAC | Switch On-Off | UL94 V-0 | 33.1 mm | 29.4 mm | 0.118 in | 3 mm | 1 mm | 0.039 in | CQC cULus ENEC | Receptacle Male Blades - Module | 10 A | 6.3 mm | Quick Connect | 0.25 " | IP40 | Panel Mount Snap-In | 2 | |
 SCHURTER Inc. | Filtered (EMI RFI) - Commercial Medical | IEC 320-C14 | Shielded V-Lock Notch | 10 A | 250 VAC | Switch On-Off | UL94 V-0 | 34.4 mm | 30.4 mm | CQC cULus ENEC | Receptacle Male Blades - Module | 10 A | 6.3 mm | Quick Connect | 0.25 " | IP40 | Flange Panel Mount |
