9310 Series

Catalog

FIXED IND 2.2UH 435MA 950MOHM TH

Part	Inductance Frequency - Test	Current Rating (Amps)	Frequency - Self Resonant	Operating Temperature [Min]	Operating Temperature [Max]	Material - Core	Inductance	Tolerance	DC Resistance (DCR) [Max]	Package / Case	Shielding	Mounting Type	Type	Size / Dimension [diameter]	Size / Dimension [x]	Size / Dimension [diameter]	Size / Dimension [x]	Q @ Freq	DC Resistance (DCR)	Q @ Freq [custom]
Bourns Inc. 9310-20-TR-RC	7.9 MHz	435 mA	135 MHz	-55 C	105 ░C	Ferrite	2.2 µH	10 %	950 mOhm	Axial	Unshielded	Through Hole	Drum Core Wirewound	0.156 in	9.53 mm	3.96 mm	0.375 in
Bourns Inc. 9310-18	7.9 MHz	525 mA	150 MHz	-55 C	105 ░C	Ferrite	1.8 µH	10 %	650 mOhm	Axial	Unshielded	Through Hole	Drum Core Wirewound	0.156 in	9.53 mm	3.96 mm	0.375 in
Bourns Inc. 9310-04-RC	25 MHz	1.4 A	360 MHz	-55 C	105 ░C	Ferrite	330 nH	20 %	90 mOhm	Axial	Unshielded	Through Hole	Drum Core Wirewound	0.156 in	9.53 mm	3.96 mm	0.375 in	25 MHz 45
Bourns Inc. 9310-32	7.9 MHz	600 mA	55 MHz	-55 C	105 ░C	Ferrite	6.8 µH	10 %	500 mOhm	Axial	Unshielded	Through Hole	Drum Core Wirewound	0.156 in	9.53 mm	3.96 mm	0.375 in	7.9 MHz 50
Bourns Inc. 9310-38-RC	2.5 MHz		42 MHz	-55 C	105 ░C	Ferrite	12 µH	10 %	1.1 Ohm	Axial	Unshielded	Through Hole	Drum Core Wirewound	0.156 in	9.53 mm	3.96 mm	0.375 in	2.5 MHz 65
Bourns Inc. 9310-04	25 MHz	1.4 A	360 MHz	-55 C	105 ░C	Ferrite	330 nH	20 %	90 mOhm	Axial	Unshielded	Through Hole	Drum Core Wirewound	0.156 in	9.53 mm	3.96 mm	0.375 in	25 MHz 45
Bourns Inc. 9310-06-TR-RC	25 MHz	1.225 A	310 MHz	-55 C	105 ░C	Ferrite	470 nH	20 %	120 mOhm	Axial	Unshielded	Through Hole	Drum Core Wirewound	0.156 in	9.53 mm	3.96 mm	0.375 in	25 MHz 45
Bourns Inc. 9310-10	25 MHz	900 mA	220 MHz	-55 C	105 ░C	Ferrite	820 nH	10 %	220 mOhm	Axial	Unshielded	Through Hole	Drum Core Wirewound	0.156 in	9.53 mm	3.96 mm	0.375 in	25 MHz 50
Bourns Inc. 9310-46-RC	2.5 MHz	0.265 A	26 MHz	-55 C	105 ░C	Ferrite	24 µH	10 %		Axial	Unshielded	Through Hole	Drum Core Wirewound	0.156 in	9.53 mm	3.96 mm	0.375 in	60	2.5 Ohm	2.5 MHz
Bourns Inc. 9310-10-RC	25 MHz	900 mA	220 MHz	-55 C	105 ░C	Ferrite	820 nH	10 %	220 mOhm	Axial	Unshielded	Through Hole	Drum Core Wirewound	0.156 in	9.53 mm	3.96 mm	0.375 in	25 MHz 50
