SBCT10 Series

Catalog

Part	Operating Temperature - Junction [Max]	Operating Temperature - Junction [Min]	Technology	Speed	Diode Configuration	Current - Average Rectified (Io) (per Diode)	Voltage - Forward (Vf) (Max) @ If [Max]	Mounting Type	Voltage - DC Reverse (Vr) (Max) [Max]	Current - Reverse Leakage @ Vr	Supplier Device Package	Package / Case	Voltage - Forward (Vf) (Max) @ If
Diotec Semiconductor SBCT1030	150 °C	-50 °C	Schottky	200 mA 500 ns	1 Pair Common Cathode	5 A	550 mV	Through Hole	30 V	300 µA	TO-220AB	TO-220-3
Diotec Semiconductor SBCT10100	150 °C	-50 °C	Schottky	200 mA 500 ns	1 Pair Common Cathode	5 A	0.92 V	Through Hole	100 V	300 µA	TO-220AB	TO-220-3	850 mV
Diotec Semiconductor SBCT1050	150 °C	-50 °C	Schottky	200 mA 500 ns	1 Pair Common Cathode	5 A	700 mV	Through Hole	50 V	300 µA	TO-220AB	TO-220-3
Diotec Semiconductor SBCT1045	150 °C	-50 °C	Schottky	200 mA 500 ns	1 Pair Common Cathode	5 A	550 mV	Through Hole	45 V	300 µA	TO-220AB	TO-220-3
