IPC70N04 Series
Manufacturer: INFINEON
Beta
⌘K
IPC70N04S5-4R6 IS AN AUTOMOTIVE MOSFET OFFERING 40V, N-CH, 4.6 MΩ MAX, SSO8 (5X6), OPTIMOS™-5, AEC Q101 QUALIFIED, 175°C OPERATING TEMPERATURE.
| Part | Gate Charge (Qg) (Max) @ Vgs [Max] | Grade | Qualification | Technology | Mounting Type | Drain to Source Voltage (Vdss) | Package / Case | Power Dissipation (Max) | Operating Temperature [Max] | Operating Temperature [Min] | Vgs (Max) | Vgs(th) (Max) @ Id | FET Type | Input Capacitance (Ciss) (Max) @ Vds [Max] | Supplier Device Package | Rds On (Max) @ Id, Vgs | Drive Voltage (Max Rds On, Min Rds On) | Current - Continuous Drain (Id) @ 25°C | Input Capacitance (Ciss) (Max) @ Vds | Gate Charge (Qg) (Max) @ Vgs |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 INFINEON | 24.2 nC | Automotive | AEC-Q101 | MOSFET (Metal Oxide) | Surface Mount | 40 V | 8-PowerTDFN | 50 W | 175 °C | -55 °C | 20 V | 3.4 V | N-Channel | 1430 pF | PG-TDSON-8-34 | 4.6 mOhm | 7 V 10 V | 70 A | ||
 INFINEON | Automotive | AEC-Q101 | MOSFET (Metal Oxide) | Surface Mount | 40 V | 8-PowerTDFN | 50 W | 175 °C | -55 °C | 16 V | 2 V | N-Channel | PG-TDSON-8-34 | 4.2 mOhm | 4.5 V 10 V | 70 A | 1600 pF | 30 nC |
