CSM-3X Series

Manufacturer: ECS Inc.

Catalog

CRYSTALS 33MHZ 20PF 50PPM -40C +85C

Part	Mounting Type	Size / Dimension [x]	Size / Dimension [y]	Size / Dimension [y]	Size / Dimension [x]	Frequency Stability	Load Capacitance	Operating Temperature [Max]	Operating Temperature [Min]	Package / Case	Frequency	ESR (Equivalent Series Resistance)	Type	Operating Mode	Height - Seated (Max) [Max]	Height - Seated (Max) [Max]	Frequency Tolerance
ECS Inc. ECS-330-20-3X-EN-TR	Surface Mount	0.276 "	4.1 mm	0.161 in	7 mm	50 ppm	20 pF	85 °C	-40 C	HC-49/US	33 MHz	40 Ohms	MHz Crystal	Fundamental	2.3 mm	0.091 in	30 ppm
ECS Inc. ECS-200-20-3X-TR	Surface Mount	0.276 "	4.1 mm	0.161 in	7 mm	50 ppm	20 pF	70 °C	-10 °C	HC-49/US	20 MHz	50 Ohms	MHz Crystal	Fundamental	2.3 mm	0.091 in	30 ppm
ECS Inc. ECS-286.3-20-3X-EN-TR	Surface Mount	0.276 "	4.1 mm	0.161 in	7 mm	50 ppm	20 pF	85 °C	-40 C	HC-49/US	28.63636 MHz	50 Ohms	MHz Crystal	Fundamental	2.3 mm	0.091 in	30 ppm
ECS Inc. ECS-160-20-3X-EN-TR	Surface Mount	0.276 "	4.1 mm	0.161 in	7 mm	50 ppm	20 pF	85 °C	-40 C	HC-49/US	16 MHz	50 Ohms	MHz Crystal	Fundamental	2.3 mm	0.091 in	30 ppm
ECS Inc. ECS-130-20-3X-EN-TR	Surface Mount	0.276 "	4.1 mm	0.161 in	7 mm	50 ppm	20 pF	85 °C	-40 C	HC-49/US	13 MHz	60 Ohms	MHz Crystal	Fundamental	2.3 mm	0.091 in	30 ppm
