TRH160A Series
Manufacturer: Cincon Electronics Co. LTD
Beta
⌘K
DESKTOP AC ADAPTERS 160W 12V 12.5A 4PIN PLUG W/LOCK
| Part | Input Connector | Applications | Approval Agency | Standard Number | No Load Power Consumption | Input Type | Power (Watts) | Region Utilized | Operating Temperature [Min] | Operating Temperature [Max] | Output Connector | Voltage - Input [Max] | Voltage - Input [Min] | Voltage - Output | Form | Efficiency | Cord Length | Cord Length | Size / Dimension [y] | Size / Dimension [x] | Size / Dimension [z] | Size / Dimension [x] | Size / Dimension [y] | Size / Dimension [z] | Current - Output (Max) [Max] | Polarization | Output Connector [custom] | Output Connector [custom] | Output Connector [x] | Output Connector [diameter] | Output Connector [z] |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 Cincon Electronics Co. LTD | IEC 320-C14 | ITE (Commercial) | CCC CE cULus FCC GS PSE TUV UKCA | 62368-1 | 75 mW | Cord (Sold Separately) | 150 W | International | -20 ░C | 70 °C | DIN 4 Pin | 264 VAC | 90 VAC | 12 V | Desktop (Class I) | CoC Tier 2 Level VI | 0.95 m | 37.4 in | 70 mm | 5.91 in | 1.5 in | 150 mm | 2.76 " | 38 mm | 12.5 A | ||||||
 Cincon Electronics Co. LTD | IEC 320-C14 | ITE (Commercial) | CCC CE cULus FCC GS PSE TUV UKCA | 62368-1 | 75 mW | Cord (Sold Separately) | 160 W | International | -20 ░C | 70 °C | Barrel Plug | 264 VAC | 90 VAC | 36 V | Desktop (Class I) | CoC Tier 2 Level VI | 1.2 m | 47 in | 70 mm | 5.91 in | 1.5 in | 150 mm | 2.76 " | 38 mm | 4.44 A | Positive Center | 2.1 mm | 5.5 mm | 12 mm | ||
Cincon Electronics Co. LTD | IEC 320-C14 | ITE (Commercial) | CCC CE cULus FCC GS PSE TUV UKCA | 62368-1 | 75 mW | Cord (Sold Separately) | 160 W | International | -20 ░C | 70 °C | Barrel Plug | 264 VAC | 90 VAC | 28 V | Desktop (Class I) | CoC Tier 2 Level VI | 1.2 m | 47 in | 70 mm | 5.91 in | 1.5 in | 150 mm | 2.76 " | 38 mm | 5.7 A | Positive Center | 2.1 mm | 5.5 mm | 12 mm | ||
Cincon Electronics Co. LTD | IEC 320-C14 | ITE (Commercial) | CCC CE cULus FCC GS PSE TUV UKCA | 62368-1 | 75 mW | Cord (Sold Separately) | 160 W | International | -20 ░C | 70 °C | Barrel Plug | 264 VAC | 90 VAC | 48 V | Desktop (Class I) | CoC Tier 2 Level VI | 1.2 m | 47 in | 70 mm | 5.91 in | 1.5 in | 150 mm | 2.76 " | 38 mm | 3.33 A | Positive Center | 2.1 mm | 5.5 mm | 12 mm | ||
Cincon Electronics Co. LTD | IEC 320-C14 | ITE (Commercial) | CE cULus FCC GS PSE TUV UKCA | 62368-1 | 150 mW | Cord (Sold Separately) | 160 W | International | -20 ░C | 70 °C | Barrel Plug | 264 VAC | 90 VAC | 56 V | Desktop (Class I) | CoC Tier 2 Level VI | 1.8 m | 70.8 in | 70 mm | 5.91 in | 1.5 in | 150 mm | 2.76 " | 38 mm | 2.85 A | Positive Center | 12 mm | 2.5 mm 5.5 mm | |||
Cincon Electronics Co. LTD | IEC 320-C14 | ITE (Commercial) | CCC CE cULus FCC GS PSE TUV UKCA | 62368-1 | 75 mW | Cord (Sold Separately) | 160 W | International | -20 ░C | 70 °C | Barrel Plug R/A | 264 VAC | 90 VAC | 24 V | Desktop (Class I) | CoC Tier 2 Level VI | 1.2 m | 47 in | 70 mm | 5.91 in | 1.5 in | 150 mm | 2.76 " | 38 mm | 6.66 A | Positive Center | 2.1 mm 5.5 mm | 12 mm | |||
Cincon Electronics Co. LTD | IEC 320-C14 | ITE (Commercial) | CCC CE cULus FCC GS PSE TUV UKCA | 62368-1 | 75 mW | Cord (Sold Separately) | 18 W | International | -20 ░C | 70 °C | Barrel Plug | 264 VAC | 90 VAC | 3.3 V | Desktop (Class I) | CoC Tier 2 Level VI | 1.2 m | 47 in | 70 mm | 5.91 in | 1.5 in | 150 mm | 2.76 " | 38 mm | 5.31 A | Positive Center | 2.1 mm | 5.5 mm | 12 mm | ||
Cincon Electronics Co. LTD | IEC 320-C14 | ITE (Commercial) | CCC CE cULus FCC GS PSE TUV UKCA | 62368-1 | 75 mW | Cord (Sold Separately) | 144 W | International | -20 ░C | 70 °C | Barrel Plug | 264 VAC | 90 VAC | 56 V | Desktop (Class I) | CoC Tier 2 Level VI | 1.2 m | 47 in | 70 mm | 5.91 in | 1.5 in | 150 mm | 2.76 " | 38 mm | 2.85 A | Positive Center | 2.1 mm | 5.5 mm | 12 mm | ||
Cincon Electronics Co. LTD | IEC 320-C14 | ITE (Commercial) | CE cULus FCC GS PSE TUV UKCA | 62368-1 | 150 mW | Cord (Sold Separately) | 160 W | International | -20 ░C | 70 °C | Barrel Plug | 264 VAC | 90 VAC | 28 V | Desktop (Class I) | CoC Tier 2 Level VI | 1.8 m | 70.8 in | 70 mm | 5.91 in | 1.5 in | 150 mm | 2.76 " | 38 mm | 5.7 A | Positive Center | 12 mm | 2.5 mm 5.5 mm | |||
Cincon Electronics Co. LTD | IEC 320-C14 | ITE (Commercial) | CE cULus FCC GS PSE TUV UKCA | 62368-1 | 150 mW | Cord (Sold Separately) | 160 W | International | -20 ░C | 70 °C | Barrel Plug | 264 VAC | 90 VAC | 48 V | Desktop (Class I) | CoC Tier 2 Level VI | 1.8 m | 70.8 in | 70 mm | 5.91 in | 1.5 in | 150 mm | 2.76 " | 38 mm | 3.33 A | Positive Center | 12 mm | 2.5 mm 5.5 mm |
