RP122 Series

Manufacturer: Nisshinbo Micro Devices Inc.

Catalog

LDO REGULATOR POS 2.8V 0.4A 4-PIN DFN EP T/R

Part	PSRR [Min]	PSRR [Max]	Protection Features	Package / Case	Current - Output	Operating Temperature [Max]	Operating Temperature [Min]	Control Features	Current - Quiescent (Iq)	Voltage - Output (Min/Fixed)	Number of Regulators	Mounting Type	Supplier Device Package	Voltage Dropout (Max)	Output Configuration	Voltage - Input (Max) [Max]	Voltage - Output (Min/Fixed) [Min]	Voltage Dropout (Max) [Max]
Nisshinbo Micro Devices Inc. RP122K281B-TR	65 dB	90 dB	Over Current Over Temperature	4-UDFN Exposed Pad	400 mA	85 C	-40 ¯C	Enable	25 µA	2.8 V	1	Surface Mount	DFN(PL)1010-4	0.265 V	Positive	5.5 V
Nisshinbo Micro Devices Inc. RP122Z131D-TR-T	65 dB	90 dB	Over Current Over Temperature	4-XFBGA WLCSP	400 mA	85 C	-40 ¯C	Enable	25 µA		1	Surface Mount	WLCSP-4-P8		Positive	5.5 V	1.3 V
Nisshinbo Micro Devices Inc. RP122K301B-TR	65 dB	90 dB	Over Current Over Temperature	4-UDFN Exposed Pad	400 mA	85 C	-40 ¯C	Enable	25 µA	3 V	1	Surface Mount	DFN(PL)1010-4	0.265 V	Positive	5.5 V
Nisshinbo Micro Devices Inc. RP122K181D-TR	65 dB	90 dB	Over Current Over Temperature	4-UDFN Exposed Pad	400 mA	85 C	-40 ¯C	Enable	25 µA	1.8 V	1	Surface Mount	DFN(PL)1010-4	0.365 V	Positive	5.5 V
Nisshinbo Micro Devices Inc. RP122K331D-TR	65 dB	90 dB	Over Current Over Temperature	4-UDFN Exposed Pad	400 mA	85 C	-40 ¯C	Enable	25 µA	3.3 V	1	Surface Mount	DFN(PL)1010-4		Positive	5.5 V		0.245 V
Nisshinbo Micro Devices Inc. RP122Z251D-TR-F	65 dB	90 dB	Over Current Over Temperature	4-XFBGA WLCSP	400 mA	85 C	-40 ¯C	Enable	25 µA	2.5 V	1	Surface Mount	WLCSP-4-P8		Positive	5.5 V		0.24 V
Nisshinbo Micro Devices Inc. RP122Z281D-TR-F	65 dB	90 dB	Over Current Over Temperature	4-XFBGA WLCSP	400 mA	85 C	-40 ¯C	Enable	25 µA	2.8 V	1	Surface Mount	WLCSP-4-P8	0.225 V	Positive	5.5 V
