1969694 Series
Manufacturer: TE Connectivity Raychem Cable Protection
Beta
⌘K
CONN HEADER R/A 4POS 6MM
| Part | Connector Type | Voltage Rating | Material Flammability Rating | Contact Finish - Post | Termination | Applications | Contact Shape | Pitch - Mating | Pitch - Mating | Operating Temperature [Min] | Operating Temperature [Max] | Fastening Type | Number of Positions Loaded | Contact Material | Insulation Material | Shrouding | Contact Type | Insulation Color | Number of Rows | Mounting Type | Current Rating (Amps) | Number of Positions | Style | Insulation Height | Insulation Height | Features |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 TE Connectivity Raychem Cable Protection | Header | 600 VAC | UL94 V-0 | Tin | Solder | General Purpose | Rectangular | 0.236 in | 6 mm | -55 °C | 150 °C | Latch Holder | All | Copper Alloy | Nylon Polyamide (PA) | Shrouded - 4 Wall | Male Pin | Gray | 1 | Through Hole Right Angle | Varies by Wire Gauge | 4 | Board to Cable/Wire | 14.96 mm | 0.589 in | |
 TE Connectivity Raychem Cable Protection | Header | 600 VAC | UL94 V-0 | Tin | Solder | General Purpose | Rectangular | 0.236 in | 6 mm | -55 °C | 105 ░C | Latch Holder | All | Copper Alloy | Polybutylene Terephthalate (PBT) Glass Filled | Shrouded - 4 Wall | Male Pin | Natural | 1 | Through Hole Right Angle | Varies by Wire Gauge | Board to Cable/Wire | 14.96 mm | 0.589 in | Board Lock Glow Wire Compliant | |
 TE Connectivity Raychem Cable Protection | Header | 600 VAC | UL94 V-0 | Tin | Solder | General Purpose | Rectangular | 0.236 in | 6 mm | -55 °C | 105 ░C | Latch Holder | All | Copper Alloy | Polybutylene Terephthalate (PBT) Glass Filled | Shrouded - 4 Wall | Male Pin | Natural | 1 | Through Hole Right Angle | Varies by Wire Gauge | 2 | Board to Cable/Wire | 14.96 mm | 0.589 in | Board Lock Glow Wire Compliant |
 TE Connectivity Raychem Cable Protection | Header | 600 VAC | UL94 V-0 | Tin | Solder | General Purpose | Rectangular | 0.236 in | 6 mm | -55 °C | 150 °C | Latch Holder | All | Copper Alloy | Nylon Polyamide (PA) | Shrouded - 4 Wall | Male Pin | Gray | 1 | Through Hole Right Angle | Varies by Wire Gauge | 2 | Board to Cable/Wire | 14.96 mm | 0.589 in | |
 TE Connectivity Raychem Cable Protection | Header | 600 VAC | UL94 V-0 | Tin | Solder | General Purpose | Rectangular | 0.236 in | 6 mm | -55 °C | 150 °C | Latch Holder | All | Copper Alloy | Nylon Polyamide (PA) | Shrouded - 4 Wall | Male Pin | Gray | 1 | Through Hole Right Angle | Varies by Wire Gauge | Board to Cable/Wire | 14.96 mm | 0.589 in | ||
 TE Connectivity Raychem Cable Protection | Header | 600 VAC | UL94 V-0 | Tin | Solder | General Purpose | Rectangular | 0.236 in | 6 mm | -55 °C | 105 ░C | Latch Holder | All | Copper Alloy | Polybutylene Terephthalate (PBT) Glass Filled | Shrouded - 4 Wall | Male Pin | Natural | 1 | Through Hole Right Angle | Varies by Wire Gauge | 4 | Board to Cable/Wire | 14.96 mm | 0.589 in | Board Lock Glow Wire Compliant |
