PZC01 Series

Manufacturer: Sullins Connector Solutions

Catalog

CONN HEADER R/A 1POS

Part	Contact Material	Connector Type	Number of Rows	Insulation Height	Insulation Height	Contact Length - Post	Contact Length - Post	Contact Finish - Mating	Contact Shape	Style	Current Rating (Amps)	Contact Finish Thickness - Mating	Contact Finish Thickness - Mating	Contact Finish - Post	Insulation Material	Material Flammability Rating	Number of Positions Loaded	Contact Finish Thickness - Post	Contact Finish Thickness - Post	Number of Positions	Insulation Color	Fastening Type	Mounting Type	Termination	Contact Type	Contact Length - Mating	Contact Length - Mating	Shrouding	Overall Contact Length	Overall Contact Length	Row Spacing - Mating [x]	Row Spacing - Mating [x]	Overall Contact Length	Number of Rows [custom]	Insulation Height [z]	Insulation Height [z]
Sullins Connector Solutions PZC01SBAN	Copper Alloy	Header	1	3.56 mm	0.14 in	3.05 mm	0.12 in	Gold	Square	Board to Board Cable	3 A	0.25 µm	10 µin	Tin	Polyester Thermoplastic	UL94 V-0	All	2.54 µm	100 µin	1	Black	Push-Pull	Right Angle Through Hole	Solder	Male Pin	0.23 in	5.84 mm	Unshrouded
Sullins Connector Solutions PZC01SFCN	Copper Alloy	Header	1	2.54 mm	0.1 in	8.13 mm	0.32 in	Gold	Square	Board to Board Cable	3 A	0.25 µm	10 µin	Tin	Polyester Thermoplastic	UL94 V-0	All	2.54 µm	100 µin	1	Black	Push-Pull	Through Hole	Solder	Male Pin	0.318 in	8.08 mm	Unshrouded	18.75 mm	0.738 in
Sullins Connector Solutions PZC01DAEN	Copper Alloy	Header		2.54 mm	0.1 in	13.21 mm	0.52 in	Gold	Square	Board to Board Cable	3 A	0.25 µm	10 µin	Tin	Polyester Thermoplastic	UL94 V-0	All	2.54 µm	100 µin	2	Black	Push-Pull	Through Hole	Solder	Male Pin	0.23 in	5.84 mm	Unshrouded	21.59 mm		0.1 in	2.54 mm	0.85 in	2
Sullins Connector Solutions PZC01SAHN	Copper Alloy	Header	1	2.54 mm	0.1 in	20.83 mm	0.82 in	Gold	Square	Board to Board Cable	3 A	0.25 µm	10 µin	Tin	Polyester Thermoplastic	UL94 V-0	All	2.54 µm	100 µin	1	Black	Push-Pull	Through Hole	Solder	Male Pin	0.23 in	5.84 mm	Unshrouded	29.21 mm				1.15 in
Sullins Connector Solutions PZC01DFBN	Copper Alloy	Header		2.54 mm	0.1 in	5.58 mm	0.22 in	Gold	Square	Board to Board Cable	3 A	0.25 µm	10 µin	Tin	Polyester Thermoplastic	UL94 V-0	All	2.54 µm	100 µin	2	Black	Push-Pull	Through Hole	Solder	Male Pin	0.318 in	8.08 mm	Unshrouded	16.21 mm		0.1 in	2.54 mm	0.638 in	2
Sullins Connector Solutions PZC01SBCN	Copper Alloy	Header	1	3.56 mm	0.14 in	8.13 mm	0.32 in	Gold	Square	Board to Board Cable	3 A	0.25 µm	10 µin	Tin	Polyester Thermoplastic	UL94 V-0	All	2.54 µm	100 µin	1	Black	Push-Pull	Right Angle Through Hole	Solder	Male Pin	0.23 in	5.84 mm	Unshrouded
Sullins Connector Solutions PZC01SBDN	Copper Alloy	Header	1	3.56 mm	0.14 in	10.67 mm	0.42 in	Gold	Square	Board to Board Cable	3 A	0.25 µm	10 µin	Tin	Polyester Thermoplastic	UL94 V-0	All	2.54 µm	100 µin	1	Black	Push-Pull	Right Angle Through Hole	Solder	Male Pin	0.23 in	5.84 mm	Unshrouded
Sullins Connector Solutions PZC01SACN	Copper Alloy	Header	1	2.54 mm	0.1 in	8.13 mm	0.32 in	Gold	Square	Board to Board Cable	3 A	0.25 µm	10 µin	Tin	Polyester Thermoplastic	UL94 V-0	All	2.54 µm	100 µin	1	Black	Push-Pull	Through Hole	Solder	Male Pin	0.23 in	5.84 mm	Unshrouded	16.51 mm				0.65 in
Sullins Connector Solutions PZC01DFEN	Copper Alloy	Header		2.54 mm	0.1 in	13.21 mm	0.52 in	Gold	Square	Board to Board Cable	3 A	0.25 µm	10 µin	Tin	Polyester Thermoplastic	UL94 V-0	All	2.54 µm	100 µin	2	Black	Push-Pull	Through Hole	Solder	Male Pin	0.318 in	8.08 mm	Unshrouded	23.83 mm		0.1 in	2.54 mm	0.938 in	2
Sullins Connector Solutions PZC01DGAN	Copper Alloy	Header				3.05 mm	0.12 in	Gold	Square	Board to Board Cable	3 A	0.25 µm	10 µin	Tin	Polyester Thermoplastic	UL94 V-0	All	2.54 µm	100 µin	2	Black	Push-Pull	Right Angle Through Hole	Solder	Male Pin	0.318 in	8.08 mm	Unshrouded			0.1 in	2.54 mm		2	6.1 mm	0.24 in
