4FTH9 Series
Manufacturer: MEC Switches
Beta
⌘K
SWITCH TACTILE SPST-NO 0.05A 24V
| Part | Mechanical Life | Switch Travel | Actuator Material | Features | Outline [x] | Outline [y] | Operating Temperature [Max] | Operating Temperature [Min] | Contact Rating @ Voltage | Circuit | Actuator Height off PCB, Vertical [z] | Actuator Orientation | Switch Function | Illumination | Illumination Voltage (Nominal) | Operating Force | Actuator Type | Mounting Type | Ingress Protection | Illumination Type, Color | Termination Style |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 MEC Switches | 10000000 Cycles | 1 mm | Polyphenylene Sulfide (PPS) | Sealed - Flux Protection | 10.1 mm | 10.1 mm | 85 °C | -30 ░C | 0.05 A 24 VDC | SPST-NO | 10.4 mm | Top Actuated | Off-Mom | Illuminated | 2.2 VDC | 300 gf | Plunger for Cap | Through Hole | IP67 - Dust Tight Waterproof | Green LED | PC Pin |
 MEC Switches | 10000000 Cycles | 1 mm | Polyphenylene Sulfide (PPS) | Sealed - Flux Protection | 10.1 mm | 10.1 mm | 85 °C | -30 ░C | 0.05 A 24 VDC | SPST-NO | 10.4 mm | Top Actuated | Off-Mom | Illuminated | 2 VDC | 300 gf | Plunger for Cap | Through Hole | IP67 - Dust Tight Waterproof | LED Red | PC Pin |
 MEC Switches | 10000000 Cycles | 1 mm | Polyphenylene Sulfide (PPS) | Sealed - Flux Protection | 10.1 mm | 10.1 mm | 85 °C | -30 ░C | 0.05 A 24 VDC | SPST-NO | 10.4 mm | Top Actuated | Off-Mom | Illuminated | 2 VDC | 300 gf | Plunger for Cap | Through Hole | IP67 - Dust Tight Waterproof | LED Yellow | PC Pin |
 MEC Switches | 10000000 Cycles | 1 mm | Polyphenylene Sulfide (PPS) | Sealed - Flux Protection | 10.1 mm | 10.1 mm | 85 °C | -30 ░C | 0.05 A 24 VDC | SPST-NO | 10.4 mm | Top Actuated | Off-Mom | Illuminated | 3.05 VDC | 300 gf | Plunger for Cap | Through Hole | IP67 - Dust Tight Waterproof | LED White | PC Pin |
 MEC Switches | 10000000 Cycles | 1 mm | Polyphenylene Sulfide (PPS) | Sealed - Flux Protection | 10.1 mm | 10.1 mm | 85 °C | -30 ░C | 0.05 A 24 VDC | SPST-NO | 10.4 mm | Top Actuated | Off-Mom | Illuminated | 300 gf | Plunger for Cap | Through Hole | IP67 - Dust Tight Waterproof | Blue LED | PC Pin | |
MEC Switches | 10000000 Cycles | 1 mm | Polyphenylene Sulfide (PPS) | Sealed - Flux Protection | 10.1 mm | 10.1 mm | 85 °C | -30 ░C | 0.05 A 24 VDC | SPST-NO | 10.4 mm | Top Actuated | Off-Mom | Illuminated | 2 VDC 2.2 VDC | 300 gf | Plunger for Cap | Through Hole | IP67 - Dust Tight Waterproof | Green/Red LED | PC Pin |
