345-046 Series
Manufacturer: EDAC Inc.
Catalog
CONN EDGE SINGLE FML 46POS 0.100
...
| Part | Termination Rows | Operating Temperature [Min] | Operating Temperature [Max] | Contact Type | Number of Rows | Color | Flange Feature [diameter] | Flange Feature | Flange Feature [diameter] | Contact Finish | Contact Material | Number of Positions | Material - Insulation | Mounting Type | Card Type | Pitch [x] | Pitch [x] | Read Out | Gender | Contact Finish Thickness | Contact Finish Thickness | Termination | Card Thickness [Min] | Card Thickness [Min] | Card Thickness [Max] | Card Thickness [Max] | Number of Positions/Bay/Row [custom] | Features |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 EDAC Inc. | 1 | -40 °C | 105 ░C | Cantilever | 1 | Green | 2.95 mm | Floating Bobbin Top Mount Opening | 0.116 in | Gold | Copper Alloy | 46 | Polyester Thermoplastic | Through Hole Right Angle | Non Specified - Single Edge | 2.54 mm | 0.1 in | Single | Female | 10 Áin | 0.25 Ám | Solder | 1.37 mm | 0.054 " | 1.78 mm | 0.07 in | 46 | |
 EDAC Inc. | 2 | -40 °C | 105 ░C | Cantilever | 2 | Green | 3.25 mm | Flush Mount Side Opening Unthreaded | 0.128 " | Gold | Copper Alloy | 46 | Polyester Thermoplastic | Through Hole | Non Specified - Dual Edge | 2.54 mm | 0.1 in | Dual | Female | 10 Áin | 0.25 Ám | Solder | 1.37 mm | 0.054 " | 1.78 mm | 0.07 in | 23 | |
 EDAC Inc. | 1 | -40 °C | 105 ░C | Cantilever | 1 | Green | M3 Threaded Insert Top Mount Opening | Gold | Copper Alloy | 46 | Polyester Thermoplastic | Through Hole | Non Specified - Single Edge | 2.54 mm | 0.1 in | Single | Female | 10 Áin | 0.25 Ám | Solder Eyelet(s) | 1.37 mm | 0.054 " | 1.78 mm | 0.07 in | 46 | |||
 EDAC Inc. | 2 | -40 °C | 105 ░C | Cantilever | 2 | Green | 2.95 mm | Floating Bobbin Flush Mount | 0.116 in | Gold | Copper Alloy | 46 | Polyester Thermoplastic | Through Hole | Non Specified - Dual Edge | 2.54 mm | 0.1 in | Dual | Female | 10 Áin | 0.25 Ám | Wire Wrap | 1.37 mm | 0.054 " | 1.78 mm | 0.07 in | 23 | |
EDAC Inc. | 2 | -40 °C | 105 ░C | Cantilever | 2 | Green | 2.95 mm | Floating Bobbin Top Mount Opening | 0.116 in | Gold | Copper Alloy | 46 | Polyester Thermoplastic | Through Hole | Non Specified - Dual Edge | 2.54 mm | 0.1 in | Dual | Female | 10 Áin | 0.25 Ám | Solder | 1.37 mm | 0.054 " | 1.78 mm | 0.07 in | 23 | |
 EDAC Inc. | 2 | -40 °C | 105 ░C | Cantilever | 2 | Green | M3 Threaded Insert Top Mount Opening | Gold | Copper Alloy | 46 | Polyester Thermoplastic | Through Hole | Non Specified - Dual Edge | 2.54 mm | 0.1 in | Dual | Female | 10 Áin | 0.25 Ám | Wire Wrap | 1.37 mm | 0.054 " | 1.78 mm | 0.07 in | 23 | |||
 EDAC Inc. | 1 | -40 °C | 105 ░C | Cantilever | 1 | Green | 4-40 Threaded Insert Top Mount Opening | Gold | Copper Alloy | 46 | Polyester Thermoplastic | Through Hole | Non Specified - Single Edge | 2.54 mm | 0.1 in | Single | Female | 10 Áin | 0.25 Ám | Solder | 1.37 mm | 0.054 " | 1.78 mm | 0.07 in | 46 | Card Guides | ||
 EDAC Inc. | 2 | -40 °C | 105 ░C | Cantilever | 2 | Green | 4-40 Flush Mount Threaded Insert Top Opening | Gold | Copper Alloy | 46 | Polyester Thermoplastic | Through Hole | Non Specified - Dual Edge | 2.54 mm | 0.1 in | Dual | Female | 10 Áin | 0.25 Ám | Solder | 1.37 mm | 0.054 " | 1.78 mm | 0.07 in | 23 | |||
 EDAC Inc. | 1 | -40 °C | 105 ░C | Cantilever | 1 | Green | 3.96 mm | Top Mount Opening Unthreaded | 0.156 in | Gold | Copper Alloy | 46 | Polyester Thermoplastic | Through Hole | Non Specified - Single Edge | 2.54 mm | 0.1 in | Single | Female | 10 Áin | 0.25 Ám | Wire Wrap | 1.37 mm | 0.054 " | 1.78 mm | 0.07 in | 46 | |
 EDAC Inc. | 2 | -40 °C | 105 ░C | Cantilever | 2 | Green | 4-40 Flush Mount Threaded Insert Top Opening | Gold | Copper Alloy | 46 | Polyester Thermoplastic | Through Hole Right Angle | Non Specified - Dual Edge | 2.54 mm | 0.1 in | Dual | Female | 10 Áin | 0.25 Ám | Wire Wrap | 1.37 mm | 0.054 " | 1.78 mm | 0.07 in | 23 |
