T489 Series
Manufacturer: KEMET
Beta
⌘K
TANTALUM CAPACITORS - SOLID SMD 20V 15UF 2412 10 % ESR=400MOHMS AECQ200
| Part | Lifetime @ Temp. | ESR (Equivalent Series Resistance) | Mounting Type | Voltage - Rated | Type | Ratings | Size / Dimension [y] | Size / Dimension [y] | Size / Dimension [x] | Size / Dimension [x] | Operating Temperature [Min] | Operating Temperature [Max] | Capacitance | Features | Package / Case | Tolerance | Height - Seated (Max) [Max] | Height - Seated (Max) [Max] | Manufacturer Size Code | Height - Seated (Max) [Max] [z] | Height - Seated (Max) [Max] [z] | Package / Case |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 KEMET | 2000 Hrs | 400 mOhm | Surface Mount | 20 V | Molded | AEC-Q200 | 3.2 mm | 0.126 in | 0.236 in | 6 mm | -55 C | 125 °C | 15 µF | Automotive | 2312 (6032 Metric) | 10 % | ||||||
 KEMET | 2000 Hrs | 5.4 Ohm | Surface Mount | 20 V | Molded | 1.6 mm | 0.063 " | 0.126 " | 3.2 mm | -55 C | 125 °C | 1500 nF | General Purpose | 1206 (3216 Metric) | 10 % | 1.8 mm | 0.071 in | A | ||||
 KEMET | 2000 Hrs | 3.16 Ohm | Surface Mount | 16 V | Molded | 2.8 mm | 0.11 " | 0.138 in | 3.5 mm | -55 C | 125 °C | 4.7 µF | General Purpose | 1411 | 10 % | B | 2.1 mm | 0.083 in | 3528 Metric | |||
 KEMET | 2000 Hrs | 3 Ohm | Surface Mount | 35 V | Molded | 1.6 mm | 0.063 " | 0.126 " | 3.2 mm | -55 C | 125 °C | 1 µF | General Purpose | 1206 (3216 Metric) | 10 % | 1.8 mm | 0.071 in | A | ||||
 KEMET | 2000 Hrs | 2000 mOhm | Surface Mount | 35 V | Molded | 2.8 mm | 0.11 " | 0.138 in | 3.5 mm | -55 C | 125 °C | 1 µF | General Purpose | 1411 | 10 % | B | 2.1 mm | 0.083 in | 3528 Metric | |||
 KEMET | 2000 Hrs | 350 mOhm | Surface Mount | 16 V | Molded | AEC-Q200 | 3.2 mm | 0.126 in | 0.236 in | 6 mm | -55 C | 125 °C | 47 µF | Automotive | 2312 (6032 Metric) | 10 % | ||||||
KEMET | 2000 Hrs | 200 mOhm | Surface Mount | 6.3 VDC | Molded | 4.3 mm | 0.169 " | 0.287 " | 7.3 mm | -55 C | 125 °C | 470 µF | General Purpose | 2917 (7343 Metric) | 10 % | 4.3 mm | 0.169 in | X | ||||
 KEMET | 2000 Hrs | 590 mOhm | Surface Mount | 16 V | Molded | 3.2 mm | 0.126 in | 0.236 in | 6 mm | -55 C | 125 °C | 33 ÁF | General Purpose | 2312 (6032 Metric) | 10 % | |||||||
 KEMET | 2000 Hrs | 6.6 Ohm | Surface Mount | 20 V | Molded | 1.6 mm | 0.063 " | 0.126 " | 3.2 mm | -55 C | 125 °C | 1 µF | General Purpose | 1206 (3216 Metric) | 10 % | 1.8 mm | 0.071 in | A | ||||
 KEMET | 2000 Hrs | 490 mOhm | Surface Mount | 16 V | Molded | 4.3 mm | 0.169 " | 0.287 " | 7.3 mm | -55 C | 125 °C | 68 µF | General Purpose | 2917 (7343 Metric) | 20 % | D | 3.1 mm | 0.122 in |
