896-048 Series
Manufacturer: EDAC Inc.
Beta
⌘K
CONN EDGE DUAL FMALE 48POS 0.125
| Part | Termination Rows [custom] | Material - Insulation | Termination | Contact Finish | Color | Mounting Type | Card Type | Pitch | Pitch | Contact Finish Thickness | Contact Finish Thickness | Gender | Number of Positions/Bay/Row | Number of Positions | Read Out | Contact Type | Contact Material | Card Thickness [Max] | Card Thickness [Min] | Operating Temperature [Max] | Operating Temperature [Min] | Flange Feature | Flange Feature [diameter] | Flange Feature [diameter] | Number of Rows [custom] | Termination Rows | Number of Rows | Features |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 EDAC Inc. | 2 | Polyphenylene Sulfide (PPS) | Wire Wrap | Gold | Black | Through Hole | Non Specified - Dual Edge | 3.18 mm | 0.125 in | 0.25 Ám | 10 Áin | Female | 24 | 48 | Dual | Cantilever | Copper Alloy | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 125 °C | -40 C | Floating Bobbin Top Mount Opening | 0.116 " | 2.95 mm | 2 | |||
 EDAC Inc. | 2 | Polyphenylene Sulfide (PPS) | Wire Wrap | Gold | Black | Through Hole | Non Specified - Dual Edge | 3.18 mm | 0.125 in | 0.25 Ám | 10 Áin | Female | 24 | 48 | Dual | Cantilever | Copper Alloy | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 125 °C | -40 C | Flush Mount M3 Threaded Insert Top Opening | 2 | |||||
 EDAC Inc. | Polyphenylene Sulfide (PPS) | Solder | Gold | Black | Through Hole | Non Specified - Single Edge | 3.18 mm | 0.125 in | 0.25 Ám | 10 Áin | Female | 48 | 48 | Single | Cantilever | Copper Alloy | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 125 °C | -40 C | Floating Bobbin Top Mount Opening | 0.116 " | 2.95 mm | 1 | 1 | |||
 EDAC Inc. | Polyphenylene Sulfide (PPS) | Wire Wrap | Gold | Black | Through Hole | Non Specified - Single Edge | 3.18 mm | 0.125 in | 0.25 Ám | 10 Áin | Female | 48 | 48 | Single | Cantilever | Copper Alloy | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 125 °C | -40 C | Floating Bobbin Top Mount Opening | 0.116 " | 2.95 mm | 1 | 1 | |||
 EDAC Inc. | Polyphenylene Sulfide (PPS) | Solder | Gold | Black | Right Angle Through Hole | Non Specified - Single Edge | 3.18 mm | 0.125 in | 0.25 Ám | 10 Áin | Female | 48 | 48 | Single | Cantilever | Copper Alloy | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 125 °C | -40 C | M3 Threaded Insert Top Mount Opening | 1 | 1 | |||||
 EDAC Inc. | 2 | Polyphenylene Sulfide (PPS) | Solder | Gold | Black | Through Hole | Non Specified - Dual Edge | 3.18 mm | 0.125 in | 0.25 Ám | 10 Áin | Female | 24 | 48 | Dual | Cantilever | Copper Alloy | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 125 °C | -40 C | 2 | ||||||
 EDAC Inc. | 2 | Polyphenylene Sulfide (PPS) | Solder Eyelet(s) | Gold | Black | Board Edge Straddle Mount | Non Specified - Dual Edge | 3.18 mm | 0.125 in | 0.25 Ám | 10 Áin | Female | 24 | 48 | Dual | Cantilever | Copper Alloy | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 125 °C | -40 C | 0.128 " | 3.25 mm | 2 | Card Extender | |||
 EDAC Inc. | 2 | Polyphenylene Sulfide (PPS) | Solder Eyelet(s) | Gold | Black | Board Edge Straddle Mount | Non Specified - Dual Edge | 3.18 mm | 0.125 in | 0.25 Ám | 10 Áin | Female | 24 | 48 | Dual | Cantilever | Copper Alloy | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 125 °C | -40 C | Flush Mount Side Opening Unthreaded | 0.128 " | 3.25 mm | 2 | Card Extender | ||
 EDAC Inc. | 2 | Polyphenylene Sulfide (PPS) | Solder | Gold | Black | Through Hole | Non Specified - Dual Edge | 3.18 mm | 0.125 in | 0.25 Ám | 10 Áin | Female | 24 | 48 | Dual | Cantilever | Copper Alloy | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 125 °C | -40 C | Flush Mount Side Opening Unthreaded | 0.128 " | 3.25 mm | 2 | |||
 EDAC Inc. | 2 | Polyphenylene Sulfide (PPS) | Solder | Gold | Black | Board Edge Straddle Mount | Non Specified - Dual Edge | 3.18 mm | 0.125 in | 0.25 Ám | 10 Áin | Female | 24 | 48 | Dual | Cantilever | Copper Alloy | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 125 °C | -40 C | Floating Bobbin Top Mount Opening | 0.116 " | 2.95 mm | 2 | Card Extender |
