PSK2420 Series

Catalog

DC/DC CONVERTER 24V 480W

Part	Efficiency	Approval Agency	Voltage - Output 1	Voltage - Input (Max) [Max]	Type	Size / Dimension [y]	Size / Dimension [x]	Size / Dimension [z]	Size / Dimension [z]	Size / Dimension [x]	Size / Dimension [y]	Number of Outputs	Applications	Mounting Type	Voltage - Input (Min) [Min]	Current - Output (Max) [Max]	Power (Watts)	Operating Temperature [Max]	Operating Temperature [Min]	Input Type	Features	DC Voltage - Input (Max) [Max]	Standard Number	DC Voltage - Input (Min) [Min]
Bel Fuse Inc. PSK2420-7	94 %	cCSAus CE	24 V	80 V	Conformal Coated Enclosed	4.37 in	6.73 in	80 mm	3.15 in	171 mm	111 mm	1	ITE (Commercial) Railway	Chassis Mount	29 V	20 A	480 W	71 °C	-25 °C
Bel Fuse Inc. PSK2420-9EC	94 %	cCSAus CE	24 V			4.37 in	6.77 in	80 mm	3.15 in	171.9 mm	111 mm	1	ITE (Commercial) Railway			20 A	480 W	71 °C	-40 °C	DC	Adjustable Output Remote On/Off Remote Sense	80 V	60950-1	29 V
Bel Fuse Inc. PSK2420-9EKB1G	94 %	cCSAus CE	24 V			4.37 in	6.77 in	80 mm	3.15 in	171.9 mm	111 mm	1	ITE (Commercial) Railway			20 A	480 W	71 °C	-40 °C	DC	Adjustable Output Remote On/Off Remote Sense	80 V	60950-1	29 V
Bel Fuse Inc. PSK2420-9EG	95 %	cCSAus CE	24 V	80 V	Conformal Coated Enclosed	4.37 in	6.73 in	80 mm	3.15 in	171 mm	111 mm	1	ITE (Commercial) Railway	Chassis Mount	29 V	20 A	480 W	71 °C	-40 C
Bel Fuse Inc. PSK2420-7EB	95 %	cCSAus CE	24 V	80 V	Conformal Coated Enclosed	2.36 "	6.73 in	80 mm	3.15 in	171 mm	168.5 mm	1	ITE (Commercial) Railway	Chassis Mount	29 V	20 A	480 W	71 °C	-25 °C
