2172070 Series
Manufacturer: TE Connectivity Raychem Cable Protection
Beta
⌘K
M12.MALE.PNLREAR.ACODE.4P.PCBSTAND.STRT
| Part | Current Rating (Amps) | Shell Finish | Shell Material | Contact Finish - Mating | Operating Temperature [Max] | Operating Temperature [Min] | Primary Material | Features | Orientation | Connector Type | Number of Positions | Color | Shell Size - Insert | Mounting Feature | Ingress Protection | Applications | Mounting Type | Voltage Rating | Termination |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 TE Connectivity Raychem Cable Protection | 4 A | Nickel | Brass | Gold | 85 °C | -40 °C | Metal | Board Guide Board Lock | A | Male Pins Receptacle | 4 | Silver | M12-4 | Bulkhead | IP68 - Dust Tight Waterproof | Automotive Industrial | Panel Mount Through Hole | 250 VDC | Solder |
 TE Connectivity Raychem Cable Protection | 2 A | Nickel | Brass | Gold | 85 °C | -40 °C | Metal | Board Guide Board Lock | A | Male Pins Receptacle | 8 | Silver | M12-8 | Bulkhead | IP68 - Dust Tight Waterproof | Automotive Industrial | Panel Mount Through Hole | 60 VDC | Solder |
