R14179 Series
Manufacturer: Radiall USA, Inc.
Beta
⌘K
BNC / QUAD FEMALE-FEMALE/FEMALE-
| Part | Body Finish | Mating Cycles | Body Material | Center Contact Material | Dielectric Material | Operating Temperature [Min] | Operating Temperature [Max] | Frequency - Max [Max] | Mounting Type | Center Contact Plating | Convert To (Adapter End) | Style | Adapter Type | Impedance | Adapter Series | Convert From (Adapter End) | Conversion Type | Fastening Type |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 Radiall USA, Inc. | Nickel | 500 | Brass | Beryllium Copper Brass | Polytetrafluoroethylene (PTFE) | -65 ░C | 165 °C | 4 GHz | Free Hanging (In-Line) | Gold | BNC Jack Female Socket (3) | Cross-Shape | Plug to Jack | 50 Ohms | BNC to BNC Triple | BNC Plug Male Pin | Same Series | Bayonet Lock |
