663-025 Series
Manufacturer: EDAC Inc.
Beta
⌘K
663 SERIES RIGHT ANGLE DUAL D-SU
| Part | Operating Temperature [Min] | Operating Temperature [Max] | Dielectric Material | Contact Material | Color | Shell Size, Connector Layout | Current Rating (Amps) | Flange Feature | Contact Finish Thickness | Connector Type | Number of Positions | Shell Material, Finish | Contact Type | Features | Mounting Type | Contact Finish | Backset Spacing | Backset Spacing | Material Flammability Rating | Termination | Connector Style | Number of Rows [custom] | Contact Finish Thickness | Contact Finish Thickness | Flange Feature |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 EDAC Inc. | -55 C | 85 °C | Polyester Thermoplastic | Brass Phosphor Bronze | Black | 3 (DB B) | 3 A | Housing/Shell (Unthreaded) | Flash | Plug Male Pins Receptacle Female Sockets | 25 | Nickel Plated Steel | Signal | Board Lock Grounding Indents Mounting Brackets Shielded | Right Angle Through Hole | Gold | 8.08 mm | 0.318 " | UL94 V-0 | Solder | D-Sub - Stacked | 2 | |||
 EDAC Inc. | -55 C | 85 °C | Polyester Thermoplastic | Brass Phosphor Bronze | Black | 3 (DB B) | 3 A | Housing/Shell (M3) | Plug Male Pins Receptacle Female Sockets | 25 | Nickel Plated Steel | Signal | Board Lock Grounding Indents Mounting Brackets Shielded | Right Angle Through Hole | Gold | 8.08 mm | 0.318 " | UL94 V-0 | Solder | D-Sub - Stacked | 2 | 30 Áin | 0.76 Ám | ||
 EDAC Inc. | -55 C | 85 °C | Polyester Thermoplastic | Brass Phosphor Bronze | Black | 3 (DB B) | 3 A | Housing/Shell | Plug Male Pins Receptacle Female Sockets | 25 | Nickel Plated Steel | Signal | Grounding Indents Shielded | Right Angle Through Hole | Gold | 8.08 mm | 0.318 " | UL94 V-0 | Solder | D-Sub - Stacked | 2 | 30 Áin | 0.76 Ám | 4-40 | |
 EDAC Inc. | -55 C | 85 °C | Polyester Thermoplastic | Brass Phosphor Bronze | Black | 3 (DB B) | 3 A | Housing/Shell | Flash | Plug Male Pins Receptacle Female Sockets | 25 | Nickel Plated Steel | Signal | Grounding Indents Shielded | Right Angle Through Hole | Gold | 8.08 mm | 0.318 " | UL94 V-0 | Solder | D-Sub - Stacked | 2 | 4-40 | ||
 EDAC Inc. | -55 C | 85 °C | Polyester Thermoplastic | Brass Phosphor Bronze | Black | 3 (DB B) | 3 A | Housing/Shell (Unthreaded) | Plug Male Pins Receptacle Female Sockets | 25 | Nickel Plated Steel | Signal | Grounding Indents Mounting Brackets Shielded | Right Angle Through Hole | Gold | 8.08 mm | 0.318 " | UL94 V-0 | Solder | D-Sub - Stacked | 2 | 15 µin | 0.38 µm | ||
 EDAC Inc. | -55 C | 85 °C | Polyester Thermoplastic | Brass Phosphor Bronze | Black | 3 (DB B) | 3 A | Housing/Shell (M3) | Plug Male Pins Receptacle Female Sockets | 25 | Nickel Plated Steel | Signal | Grounding Indents Shielded | Right Angle Through Hole | Gold | 8.08 mm | 0.318 " | UL94 V-0 | Solder | D-Sub - Stacked | 2 | 30 Áin | 0.76 Ám | ||
 EDAC Inc. | -55 C | 85 °C | Polyester Thermoplastic | Brass Phosphor Bronze | Black | 3 (DB B) | 3 A | Housing/Shell (M3) | Plug Male Pins Receptacle Female Sockets | 25 | Nickel Plated Steel | Signal | Board Lock Grounding Indents Mounting Brackets Shielded | Right Angle Through Hole | Gold | 8.08 mm | 0.318 " | UL94 V-0 | Solder | D-Sub - Stacked | 2 | 15 µin | 0.38 µm | ||
 EDAC Inc. | -55 C | 85 °C | Polyester Thermoplastic | Brass Phosphor Bronze | Black | 3 (DB B) | 3 A | Housing/Shell | Plug Male Pins Receptacle Female Sockets | 25 | Nickel Plated Steel | Signal | Board Lock Grounding Indents Mounting Brackets Shielded | Right Angle Through Hole | Gold | 8.08 mm | 0.318 " | UL94 V-0 | Solder | D-Sub - Stacked | 2 | 30 Áin | 0.76 Ám | 4-40 | |
 EDAC Inc. | -55 C | 85 °C | Polyester Thermoplastic | Brass Phosphor Bronze | Black | 3 (DB B) | 3 A | Housing/Shell | Plug Male Pins Receptacle Female Sockets | 25 | Nickel Plated Steel | Signal | Board Lock Grounding Indents Mounting Brackets Shielded | Right Angle Through Hole | Gold | 8.08 mm | 0.318 " | UL94 V-0 | Solder | D-Sub - Stacked | 2 | 30 Áin | 0.76 Ám | 4-40 | |
 EDAC Inc. | -55 C | 85 °C | Polyester Thermoplastic | Brass Phosphor Bronze | Black | 3 (DB B) | 3 A | 4-40 Mating Side Female Screwlock | Plug Male Pins Receptacle Female Sockets | 25 | Nickel Plated Steel | Signal | Grounding Indents Mounting Brackets Shielded | Right Angle Through Hole | Gold | 8.08 mm | 0.318 " | UL94 V-0 | Solder | D-Sub - Stacked | 2 | 30 Áin | 0.76 Ám |
