E2A-M18 Series
Manufacturer: Omron Electronics Inc-EMC Div
Beta
⌘K
SENSOR PROX INDUCTIVE 8MM CYLIND
| Part | Operating Temperature [Min] | Operating Temperature [Max] | Package / Case | Output Type | Sensing Distance | Sensing Distance | Termination Style | Voltage - Supply [Min] | Voltage - Supply [Max] | Shielding | Sensor Type | Material - Body | Response Frequency | Indicator [custom] | Ingress Protection |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 Omron Electronics Inc-EMC Div | -40 °C | 70 °C | Cylinder Threaded - M18 | 3-Wire NPN-NC/NO | 0.315 in | 8 mm | Connector | 10 VDC | 32 VDC | Shielded | Inductive | Nickel-Plated Brass | 500 Hz | LED | IP67 IP69K |
Omron Electronics Inc-EMC Div | -40 °C | 70 °C | Cylinder Threaded - M18 | PNP-NC 3-Wire | 0.63 in | 16 mm | Cable Leads | 10 VDC | 32 VDC | Unshielded | Inductive | Nickel-Plated Brass | 400 Hz | LED | IP67 IP69K |
Omron Electronics Inc-EMC Div | -40 °C | 70 °C | Cylinder Threaded - M18 | PNP-NC 3-Wire | 0.63 in | 16 mm | Cable Leads | 10 VDC | 32 VDC | Unshielded | Inductive | Nickel-Plated Brass | 400 Hz | LED | IP67 IP69K |
Omron Electronics Inc-EMC Div | -40 °C | 70 °C | Cylinder Threaded - M18 | NPN-NC 3-Wire | 0.315 in | 8 mm | Connector | 10 VDC | 32 VDC | Shielded | Inductive | Nickel-Plated Brass | 500 Hz | LED | IP67 IP69K |
 Omron Electronics Inc-EMC Div | -40 °C | 70 °C | Cylinder Threaded - M18 | NPN-NO 3-Wire | 0.315 in | 8 mm | Connector | 10 VDC | 32 VDC | Shielded | Inductive | Nickel-Plated Brass | 500 Hz | LED | IP67 IP69K |
Omron Electronics Inc-EMC Div | -40 °C | 70 °C | Cylinder Threaded - M18 | NPN-NC 2-Wire | 0.315 in | 8 mm | Connector | 10 VDC | 32 VDC | Shielded | Inductive | Nickel-Plated Brass | 500 Hz | LED | IP67 IP69K |
 Omron Electronics Inc-EMC Div | -40 °C | 70 °C | Cylinder Threaded - M18 | PNP-NO 3-Wire | 0.315 in | 8 mm | Cable Leads | 10 VDC | 32 VDC | Shielded | Inductive | Nickel-Plated Brass | 500 Hz | LED | IP67 IP69K |
 Omron Electronics Inc-EMC Div | -40 °C | 70 °C | Cylinder Threaded - M18 | PNP-NO 3-Wire | 0.63 in | 16 mm | Connector | 10 VDC | 32 VDC | Unshielded | Inductive | Nickel-Plated Brass | 400 Hz | LED | IP67 IP69K |
Omron Electronics Inc-EMC Div | -40 °C | 70 °C | Cylinder Threaded - M18 | PNP-NO 3-Wire | 0.315 in | 8 mm | Cable Leads | 10 VDC | 32 VDC | Shielded | Inductive | Nickel-Plated Brass | 500 Hz | LED | IP67 IP69K |
 Omron Electronics Inc-EMC Div | -40 °C | 70 °C | Cylinder Threaded - M18 | 3-Wire NPN-NC/NO | 0.63 in | 16 mm | Connector | 10 VDC | 32 VDC | Unshielded | Inductive | Nickel-Plated Brass | 400 Hz | LED | IP67 IP69K |
