8P1P Series

Catalog

CIRCULAR CONNECTOR, QUIK-LOQ 8P1P SERIES, CABLE MOUNT PLUG, 8 CONTACTS, SOLDER PIN, PUSH-PULL

Part	Fastening Type	Mounting Type	Cable Opening [Max]	Cable Opening [Min]	Cable Opening [Min]	Cable Opening [Max]	Color	Contact Finish Thickness - Mating	Contact Finish Thickness - Mating	Insert Material	Features	Contact Material	Shielding	Current Rating (Amps)	Operating Temperature [Max]	Operating Temperature [Min]	Primary Material	Shell Material	Ingress Protection	Orientation	Voltage Rating	Contact Finish - Mating	Number of Positions	Connector Type	Termination	Mounting Feature
NorComp Inc. 8P1P00817BVL521	Push-Pull	Free Hanging (In-Line)	0.197 in	4 mm	0.157 in	5 mm	Gray Green	7 µin	0.178 µm	Polyphenylene Sulfide (PPS)	Backshell Strain Relief	Copper Alloy	Unshielded	5 A	120 °C	-20 ░C	Plastic	Polyacrylonitrile Butadiene Styrene (ABS) Polycarbonate (PC)	IP50 - Dust Protected	Keyed	400 V	Gold	8	Plug Male Pins
NorComp Inc. 8P1P002210JRB01	Push-Pull	Panel Mount Through Hole					Gray Yellow	7 µin	0.178 µm	Polyphenylene Sulfide (PPS)		Copper Alloy	Unshielded	10 A	120 °C	-20 ░C	Plastic	Polyacrylonitrile Butadiene Styrene (ABS) Polycarbonate (PC)	IP50 - Dust Protected	Keyed	500 V	Gold	2	Receptacle Female Sockets	Solder	Bulkhead - Front Side Nut
NorComp Inc. 8P1P01417BNL621	Push-Pull	Free Hanging (In-Line)	0.236 in	5 mm	0.197 in	6 mm		7 µin	0.178 µm	Polyphenylene Sulfide (PPS)	Backshell Strain Relief	Copper Alloy	Unshielded	3 A	120 °C	-20 ░C	Plastic	Polyacrylonitrile Butadiene Styrene (ABS) Polycarbonate (PC)	IP50 - Dust Protected	Keyed	333 V	Gold	14	Plug Male Pins
NorComp Inc. 8P1P01417BGL621	Push-Pull	Free Hanging (In-Line)	0.236 in	5 mm	0.197 in	6 mm	Gray	7 µin	0.178 µm	Polyphenylene Sulfide (PPS)	Backshell Strain Relief	Copper Alloy	Unshielded	3 A	120 °C	-20 ░C	Plastic	Polyacrylonitrile Butadiene Styrene (ABS) Polycarbonate (PC)	IP50 - Dust Protected	Keyed	333 V	Gold	14	Plug Male Pins
NorComp Inc. 8P1P00317NVL421	Push-Pull	Free Hanging (In-Line)	0.157 in	2.2 mm	0.087 in	3.99 mm	Gray Green	7 µin	0.178 µm	Polyphenylene Sulfide (PPS)		Copper Alloy	Unshielded	10 A	120 °C	-20 ░C	Plastic	Polyacrylonitrile Butadiene Styrene (ABS) Polycarbonate (PC)	IP50 - Dust Protected	Keyed	500 V	Gold		Plug Male Pins
NorComp Inc. 8P1P00817BGL521	Push-Pull	Free Hanging (In-Line)	0.197 in	4 mm	0.157 in	5 mm	Gray	7 µin	0.178 µm	Polyphenylene Sulfide (PPS)	Backshell Strain Relief	Copper Alloy	Unshielded	5 A	120 °C	-20 ░C	Plastic	Polyacrylonitrile Butadiene Styrene (ABS) Polycarbonate (PC)	IP50 - Dust Protected	Keyed	400 V	Gold	8	Plug Male Pins
NorComp Inc. 8P1P00517BGL521	Push-Pull	Free Hanging (In-Line)	0.197 in	4 mm	0.157 in	5 mm	Gray	7 µin	0.178 µm	Polyphenylene Sulfide (PPS)	Backshell Strain Relief	Copper Alloy	Unshielded	8 A	120 °C	-20 ░C	Plastic	Polyacrylonitrile Butadiene Styrene (ABS) Polycarbonate (PC)	IP50 - Dust Protected	Keyed	500 V	Gold	5	Plug Male Pins
NorComp Inc. 8P1P010210NRBR1	Push-Pull	Panel Mount Right Angle Through Hole						7 µin	0.178 µm	Polyphenylene Sulfide (PPS)		Copper Alloy	Unshielded	3 A	120 °C	-20 ░C	Plastic	Polyacrylonitrile Butadiene Styrene (ABS) Polycarbonate (PC)	IP50 - Dust Protected	Keyed	333 V	Gold	10	Receptacle Female Sockets	Solder	Bulkhead - Front Side Nut
NorComp Inc. 8P1P00917BGL521	Push-Pull	Free Hanging (In-Line)	0.197 in	4 mm	0.157 in	5 mm	Gray	7 µin	0.178 µm	Polyphenylene Sulfide (PPS)	Backshell Strain Relief	Copper Alloy	Unshielded	3 A	120 °C	-20 ░C	Plastic	Polyacrylonitrile Butadiene Styrene (ABS) Polycarbonate (PC)	IP50 - Dust Protected	Keyed	333 V	Gold	9	Plug Male Pins
NorComp Inc. 8P1P002210GRBR1	Push-Pull	Panel Mount Right Angle Through Hole					Gray	7 µin	0.178 µm	Polyphenylene Sulfide (PPS)		Copper Alloy	Unshielded	10 A	120 °C	-20 ░C	Plastic	Polyacrylonitrile Butadiene Styrene (ABS) Polycarbonate (PC)	IP50 - Dust Protected	Keyed	500 V	Gold	2	Receptacle Female Sockets	Solder	Bulkhead - Front Side Nut
