PZL Series
Manufacturer: Rubycon
Beta
⌘K
ALUMINUM ORGANIC POLYMER CAPACITORS 35VDC 150UF 20% AEC-Q200
| Part | Package / Case | Tolerance | Lifetime @ Temp. | Ripple Current @ High Frequency | Height - Seated (Max) [Max] | Height - Seated (Max) [Max] | Operating Temperature [Min] | Operating Temperature [Max] | Size / Dimension [diameter] | Size / Dimension [diameter] | Ratings | Ripple Current @ Low Frequency | Type | Lead Spacing | Lead Spacing | Voltage - Rated | ESR (Equivalent Series Resistance) | Mounting Type | Applications | Capacitance |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 Rubycon | Can Radial | 20 % | 1000 Hrs | 1.8 A | 0.413 " | 10.5 mm | -55 C | 150 °C | 0.394 in | 10 mm | AEC-Q200 | 90 mA | Hybrid | 0.197 " | 5 mm | 35 V | 20 mOhms | Through Hole | Automotive | 150 µF |
Rubycon | Can Radial | 20 % | 1000 Hrs | 1.4 A | 0.413 " | 10.5 mm | -55 C | 150 °C | 0.315 in | 8 mm | AEC-Q200 | 70 mA | Hybrid | 0.138 in | 3.5 mm | 35 V | 25 mOhm | Through Hole | Automotive | 100 µF |
