SLF-H Series

Catalog

POWER INDUCTORS - SMD 150UH 0.5A AEC-Q200

Part	Package / Case	Tolerance	Mounting Type	Material - Core	Shielding	Current - Saturation (Isat)	Type	Size / Dimension [x]	Size / Dimension [y]	Size / Dimension [y]	Size / Dimension [x]	Inductance	DC Resistance (DCR) [Max]	Current Rating (Amps)	Height - Seated (Max) [Max]	Height - Seated (Max)	Operating Temperature [Max]	Operating Temperature [Min]	Inductance Frequency - Test	Ratings	DC Resistance (DCR)	Height - Seated (Max) [Max]
TDK Corporation SLF7045T-151MR50-H	Nonstandard	20 %	Surface Mount	Ferrite	Shielded	500 mA	Drum Core Wirewound	0.276 "	0.276 in	7 mm	7 mm	150 µH	660 mOhm	0.5 A	0.189 "	4.8 mm	125 °C	-40 C	100 kHz	AEC-Q200
TDK Corporation SLF10145T-150M2R2-H	Nonstandard	20 %	Surface Mount	Ferrite	Shielded	2.4 A	Drum Core Wirewound	0.398 in	0.398 in	10.1 mm	10.1 mm	15 µH	56.64 mOhm	2.2 A	0.189 "	4.8 mm	125 °C	-40 C	1 kHz	AEC-Q200
TDK Corporation SLF10145T-151MR79-H	Nonstandard	20 %	Surface Mount	Ferrite	Shielded	790 mA	Drum Core Wirewound	0.398 in	0.398 in	10.1 mm	10.1 mm	150 µH		0.81 A	0.189 "	4.8 mm	125 °C	-40 C	1 kHz	AEC-Q200	420 mOhm
TDK Corporation SLF12565T-102MR45-H	Nonstandard	20 %	Surface Mount	Ferrite	Shielded	450 mA	Drum Core Wirewound	0.492 "	0.492 "	12.5 mm	12.5 mm	1 mH		0.5 A	0.27 in		125 °C	-40 C	1 kHz	AEC-Q200	2.016 Ohm	6.85 mm
