NCS2 Series
Manufacturer: Mini-Circuits
Beta
⌘K
SIGNAL CONDITIONING RF XFMR / SURF MT / ROHS
| Part | Mounting Type | Phase Difference | Package / Case | Return Loss (Min) [Min] | Insertion Loss (Max) [Max] | Impedance - Unbalanced/Balanced [custom] | Frequency Range [Min] | Frequency Range [Max] | Package / Case |
|---|---|---|---|---|---|---|---|---|---|
 Mini-Circuits | Surface Mount | 5 ° | 6-SMD No Lead | 13.67 dB | 1 dB | 1:2 | 3000 MHz | 3.9 GHz | |
 Mini-Circuits | Surface Mount | 8 ° | 0805 (2012 Metric) | 11.21 dB | 1.6 dB | 1:2 | 900 MHz | 2.3 GHz | 6 PC Pad |
