LIMIT SWITCH, SIDE ROTARY, DPDT, 10 A, 600 V, 0.45 N-M, HDLS SERIES
| Part | Actuator Type | Current Rating (Amps) | Circuit | Operating Force | Pretravel | Operating Temperature [Max] | Operating Temperature [Min] | Overtravel | Termination Style | Differential Travel | Voltage Rating - AC | Voltage Rating - DC | Switch Function | Mounting Type | Actuator Marking | Approval Agency | Features | Color - Actuator/Cap | Panel Cutout Dimensions [y] | Panel Cutout Dimensions [x] | Pretravel | Overtravel [custom] | Overtravel [custom] | Differential Travel | Release Force | Operating Position | Operating Position | Mechanical Life | Operating Force [Max] | Operating Force [Min] |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 Honeywell Sensing and Productivity Solutions | Side Rotary - No Lever | 10 A 800 mA | DPDT (DB/DM) | 46 gfm | 65 ° | 121 C | -1 °C | 20 ° | Plug In | 40 ° | 120 V | 115 V | On-On | Chassis Mount | ||||||||||||||||
 Honeywell Sensing and Productivity Solutions | Concave (Curved) | 10 A | SPST-NO | 71 °C | -54 °C | Screw Terminal | 125 V | Off-Mom | Flange Panel Mount | No Marking | CE CSA UKCA UL | Sealed | Clear | 23.9 mm | 38.4 mm | |||||||||||||||
Honeywell Sensing and Productivity Solutions | Side Plunger | 10 A 800 mA | DPDT (DB/DM) | 2720 gf | 0.1 in | 93 °C | -12 °C | Screw Terminal | 120 V | 115 V | On-Mom | Chassis Mount | 2.5 mm | 0.19 " | 4.8 mm | |||||||||||||||
Honeywell Sensing and Productivity Solutions | Concave (Curved) | 15 A | 4PDT | 71 °C | -54 °C | Screw Terminal | 125 V | On-On | Flange Panel Mount | No Marking | CE CSA UKCA UL | Sealed | Clear | |||||||||||||||||
 Honeywell Sensing and Productivity Solutions | Top Rotary - No Lever | 10 A 800 mA | SPDT (DB/DM) | 28 gfm | 25 ° | 121 C | -1 °C | Plug In | 10 ° | 120 V | 115 V | On-Mom | Chassis Mount | 110 ° | ||||||||||||||||
Honeywell Sensing and Productivity Solutions | Round (Pin Plunger) | SPDT | 125 °C | -55 C | Solder Turret | On-Mom | Chassis Mount | |||||||||||||||||||||||
Honeywell Sensing and Productivity Solutions | Round (Pin Plunger) | 10 A 800 mA | DPDT (DB/DM) | 1814 gf | 0.071 " | 93 °C | -12 °C | Plug In | 0.02 in | 120 V | 115 V | On-Mom | Chassis Mount | 1.8 mm | 0.19 " | 4.8 mm | 0.5 mm | |||||||||||||
 Honeywell Sensing and Productivity Solutions | Side Rotary - No Lever | 10 A 800 mA | SPDT (DB/DM) | 19 gfm | 9 ° | 121 C | -1 °C | Plug In | 3 ° | 120 V | 115 V | On-Mom | Chassis Mount | Status Indicator | 66 ° | |||||||||||||||
 Honeywell Sensing and Productivity Solutions | Side Rotary - No Lever | 10 A 800 mA | SPDT (DB/DM) | 46 gfm | 9 ° | 121 C | -12 °C | Plug In | 3 ° | 120 V | 115 V | On-Mom | Chassis Mount | Status Indicator | 66 ° | |||||||||||||||
Honeywell Sensing and Productivity Solutions | Round (Pin Plunger) | 15 A 500 mA | SPST-NO | 0.015 " | 85 °C | -55 C | Solder Lug | 0.002 in | 125 V | 125 VDC | Off-Mom | Chassis Mount | 0.4 mm | 0.005 " | 0.13 mm | 0.05 mm | 113 gf | 0.625 in | 15.9 mm | 20000000 Cycles | 368 gf | 255 gf |
