SMP Series
Manufacturer: Rosenberger
Beta
⌘K
RF CONNECTORS / COAXIAL CONNECTORS STRAIGHT PLUG PCB
| Part | Body Material | Operating Temperature [Max] | Operating Temperature [Min] | Center Contact Plating | Body Finish | Voltage Rating | Dielectric Material | Mating Cycles | Shield Termination | Impedance | Mounting Type | Housing Color | Connector Type | Frequency - Max [Max] | Fastening Type | Center Contact Material | Number of Ports | Contact Termination | Features | Cable Group |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 Rosenberger | Brass | 155 C | -65 ░C | Gold | Gold | 335 V | Liquid Crystal Polymer (LCP) | 1000 | Solder | 50 Ohms | Surface Mount | Gold | Plug Male Pin | 26.5 GHz | Snap-On | Brass | 1 | Solder | ||
 Rosenberger | Solder | 50 Ohms | Board Edge Cutout Surface Mount | Gold | Plug Male Pin | 26.5 GHz | Snap-On | Brass | 1 | Solder | Limited Detent | |||||||||
 Rosenberger | Solder | 50 Ohms | Free Hanging (In-Line) | Gold | Female Socket Jack | 26.5 GHz | Snap-On | Beryllium Copper | 1 | Solder | UT-47 | |||||||||
 Rosenberger | Brass | 155 C | -65 ░C | Gold | Gold | 335 V | Liquid Crystal Polymer (LCP) | 1000 | Solder | 50 Ohms | Surface Mount | Gold | Plug Male Pin | 26.5 GHz | Snap-On | Brass | 1 | Solder | Catcher's Mitt | |
 Rosenberger | Brass | 155 C | -65 ░C | Gold | Gold | 335 V | Liquid Crystal Polymer (LCP) | 1000 | Solder | 50 Ohms | Right Angle Surface Mount | Gold | Plug Male Pin | 26.5 GHz | Snap-On | Brass | 1 | Solder | ||
 Rosenberger | Brass | 155 C | -65 ░C | Gold | Gold | 335 V | Liquid Crystal Polymer (LCP) | 500 | Solder | 50 Ohms | Surface Mount Through Hole | Gold | Plug Male Pin | 26.5 GHz | Snap-On | Brass | 1 | Solder | Limited Detent | |
 Rosenberger | Brass | 155 C | -65 ░C | Gold | Gold | 335 V | Liquid Crystal Polymer (LCP) | 1000 | Solder | 50 Ohms | Surface Mount | Gold | Plug Male Pin | 26.5 GHz | Snap-On | Brass | 1 | Solder | Smooth Bore |
