29080 Series
Manufacturer: Phoenix Contact
Beta
⌘K
POWER RELAY 24VDC 16A SPST-NO(38.6X36.1X45.5)MM SOCKET
| Part | Coil Resistance | Coil Current | Relay Type | Approval Agency | Operating Temperature [Max] | Operating Temperature [Min] | Switching Voltage [Max] | Operate Time | Coil Voltage | Load - Max Switching | Termination Style | Mounting Type | Features | Contact Rating (Current) | Coil Type | Release Time | Contact Material | Contact Form |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 Phoenix Contact | 342.9 Ohms | 70 mA | General Purpose | EAC EX | 70 °C | -40 C | 350 VDC 440 VAC | 20 ms | 24 VDC | 5600 W 7040 VA | Plug In | Socketable | Magnetic Blowout | 16 A | Non Latching | 15 ms | Silver Nickel (AgNi) | SPST-NO (1 Form A) |
 Phoenix Contact | 19.17 kOhms | 12 mA | General Purpose | EAC EX | 70 °C | -40 C | 350 VDC 440 VAC | 25 ms | 230 VAC | 5600 W 7040 VA | Plug In | Socketable | Magnetic Blowout | 16 A | Non Latching | 18 ms | Silver Nickel (AgNi) | SPST-NO (1 Form A) |
