391-014 Series
Manufacturer: EDAC Inc.
Beta
⌘K
CONN EDGE SINGLE FML 14POS 0.100
| Part | Termination Rows | Material - Insulation | Contact Material | Color | Mounting Type | Flange Feature | Number of Positions | Termination | Contact Type | Contact Finish | Contact Finish Thickness | Contact Finish Thickness | Operating Temperature [Min] | Operating Temperature [Max] | Card Type | Number of Rows | Card Thickness [Max] | Card Thickness [Min] | Gender | Number of Positions/Bay/Row | Read Out | Pitch | Pitch | Termination Rows [custom] | Number of Rows [custom] | Flange Feature [diameter] | Flange Feature [diameter] | Features |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 EDAC Inc. | 1 | Polyester Thermoplastic | Copper Alloy | Black | Through Hole | Flush Mount M3 Threaded Insert Top Opening | 14 | Solder | Semi Bellows | Gold | 0.25 Ám | 10 Áin | -40 C | 105 ░C | Non Specified - Single Edge | 1 | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Female | 14 | Single | 0.1 " | 2.54 mm | |||||
 EDAC Inc. | Polyester Thermoplastic | Copper Alloy | Black | Through Hole | Floating Bobbin Flush Mount | 14 | Solder | Semi Bellows | Gold | 0.25 Ám | 10 Áin | -40 C | 105 ░C | Non Specified - Dual Edge | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Female | 7 | Dual | 0.1 " | 2.54 mm | 2 | 2 | 0.116 " | 2.95 mm | |||
 EDAC Inc. | Polyester Thermoplastic | Copper Alloy | Black | Through Hole | Floating Bobbin Flush Mount | 14 | Solder | Semi Bellows | Gold | 0.25 Ám | 10 Áin | -40 C | 105 ░C | Non Specified - Dual Edge | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Female | 7 | Dual | 0.1 " | 2.54 mm | 2 | 2 | 0.116 " | 2.95 mm | Card Extender | ||
 EDAC Inc. | Polyester Thermoplastic | Copper Alloy | Black | Through Hole | 14 | Solder | Semi Bellows | Gold | 0.25 Ám | 10 Áin | -40 C | 105 ░C | Non Specified - Dual Edge | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Female | 7 | Dual | 0.1 " | 2.54 mm | 2 | 2 | ||||||
 EDAC Inc. | Polyester Thermoplastic | Copper Alloy | Black | Through Hole | 14 | Solder | Semi Bellows | Gold | 0.25 Ám | 10 Áin | -40 C | 105 ░C | Non Specified - Dual Edge | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Female | 7 | Dual | 0.1 " | 2.54 mm | 2 | 2 | ||||||
 EDAC Inc. | 1 | Polyester Thermoplastic | Copper Alloy | Black | Through Hole | 4-40 Flush Mount Threaded Insert Top Opening | 14 | Solder | Semi Bellows | Gold | 0.25 Ám | 10 Áin | -40 C | 105 ░C | Non Specified - Single Edge | 1 | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Female | 14 | Single | 0.1 " | 2.54 mm | |||||
 EDAC Inc. | Polyester Thermoplastic | Copper Alloy | Black | Through Hole | 14 | Solder | Semi Bellows | Gold | 0.25 Ám | 10 Áin | -40 C | 105 ░C | Non Specified - Dual Edge | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Female | 7 | Dual | 0.1 " | 2.54 mm | 2 | 2 | ||||||
 EDAC Inc. | Polyester Thermoplastic | Copper Alloy | Black | Through Hole | Floating Bobbin Flush Mount | 14 | Solder | Semi Bellows | Gold | 0.25 Ám | 10 Áin | -40 C | 105 ░C | Non Specified - Dual Edge | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Female | 7 | Dual | 0.1 " | 2.54 mm | 2 | 2 | 0.116 " | 2.95 mm | |||
 EDAC Inc. | 1 | Polyester Thermoplastic | Copper Alloy | Black | Through Hole | Flush Mount Top Opening Unthreaded | 14 | Solder | Semi Bellows | Gold | 0.25 Ám | 10 Áin | -40 C | 105 ░C | Non Specified - Single Edge | 1 | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Female | 14 | Single | 0.1 " | 2.54 mm | 0.156 " | 3.96 mm | |||
 EDAC Inc. | Polyester Thermoplastic | Copper Alloy | Black | Through Hole | 4-40 Flush Mount Threaded Insert Top Opening | 14 | Solder | Semi Bellows | Gold | 0.25 Ám | 10 Áin | -40 C | 105 ░C | Non Specified - Dual Edge | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Female | 7 | Dual | 0.1 " | 2.54 mm | 2 | 2 | Card Extender |
