ADXL323 Series

Small, Low Power, 2-Axis ±3giMEMS® Accelerometer

Manufacturer: Analog Devices Inc./Maxim Integrated

Catalog

Small, Low Power, 2-Axis ±3giMEMS® Accelerometer

Part	Supplied Contents	Sensitivity	Utilized IC / Part	Sensing Range	Voltage - Supply [Max]	Voltage - Supply [Min]	Interface	Sensor Type	Contents	Mounting Type	Acceleration Range [Min]	Acceleration Range [Max]	Type	Package / Case	Output Type	Operating Temperature [Min]	Operating Temperature [Max]	Supplier Device Package	Axis	Bandwidth	Sensitivity (mV/g)
Analog Devices Inc./Maxim Integrated EVAL-ADXL323Z	Board(s)	300 fF/%RH	ADXL323	3.6 g	5.25 V	1.8 V	Analog	Accelerometer 2 Axis	Board(s)
Analog Devices Inc./Maxim Integrated ADXL323KCPZ					5.25 V	1.8 V				Surface Mount	-3.6 g	3.6 g	Analog	16-LQFN Exposed Pad CSP	Analog Voltage	-25 °C	70 °C	16-LFCSP-LQ (4x4)	X Y	1.6 kHz	300 mV/g
Analog Devices Inc./Maxim Integrated ADXL323KCPZ-RL					5.25 V	1.8 V				Surface Mount	-3.6 g	3.6 g		16-LQFN Exposed Pad CSP				16-LFCSP-LQ (4x4)	X Y

Catalog

Small, Low Power, 2-Axis ±3giMEMS® Accelerometer

Description

The ADXL323 is a small, thin, low power, complete 2-axis accelerometer with signal-conditioned voltage outputs, all on a single, monolithic IC. The product measures acceleration with a minimum full-scale range of ±3 g. It can measure the static acceleration of gravity in tilt-sensing applications, as well as dynamic acceleration resulting from motion, shock, or vibration.The user selects the bandwidth of the accelerometer using the CXand CYcapacitors at the XOUTand YOUTpins. Bandwidths can be selected to suit the application, with a range of 0.5 Hz to 1600 Hz.The ADXL323 is available in a small, low profile, 4 mm × 4 mm × 1.45 mm, 16-lead, plastic lead frame chip scale package (LFCSP_LQ)APPLICATIONSCost-sensitive, low power, motion- and tilt-sensing applicationsMobile devicesGaming systemsDisk drive protectionImage stabilizationSports and health devices
