TLM3 Series

Catalog

CURRENT SENSE RES, 0R039, 5%, 1 W, 2512

Part	Number of Terminations [custom]	Features	Resistance	Package / Case	Supplier Device Package	Temperature Coefficient	Operating Temperature [Max]	Operating Temperature [Min]	Size / Dimension [y]	Size / Dimension [x]	Size / Dimension [y]	Size / Dimension [x]	Height - Seated (Max) [Max] [z]	Height - Seated (Max) [Max] [z]	Power (Watts)	Tolerance	Height - Seated (Max) [Max]	Height - Seated (Max) [Max]
TE Connectivity AMP Connectors TLM3AER039JTE	2	Current Sense	39 mOhms	2512 (6432 Metric)	2512	100 ppm/°C	155 C	-55 C	3.15 mm	6.3 mm	0.124 in	0.248 in	0.7 mm	0.028 "	1 W	5 %
TE Connectivity AMP Connectors TLM3AER027JTE	2	Current Sense	27 mOhms	2512 (6432 Metric)	2512	100 ppm/°C	155 C	-55 C	3.15 mm	6.3 mm	0.124 in	0.248 in			1 W	5 %	0.73 mm	0.029 in
TE Connectivity AMP Connectors TLM3AER047JTE	2	Current Sense	47 mOhms	2512 (6432 Metric)	2512	100 ppm/°C	155 C	-55 C	3.15 mm	6.3 mm	0.124 in	0.248 in	0.7 mm	0.028 "	1 W	5 %
TE Connectivity AMP Connectors TLM3AER018JTE	2	Current Sense	18 mOhms	2512 (6432 Metric)	2512	100 ppm/°C	155 C	-55 C	3.15 mm	6.3 mm	0.124 in	0.248 in			1 W	5 %	0.73 mm	0.029 in
TE Connectivity AMP Connectors TLM3AER022JTE	2	Current Sense	22 mOhms	2512 (6432 Metric)	2512	100 ppm/°C	155 C	-55 C	3.15 mm	6.3 mm	0.124 in	0.248 in			1 W	5 %	0.73 mm	0.029 in
