VL-EBX Series
Manufacturer: VersaLogic Corporation
Beta
⌘K
SBC 933MHZ 1 CORE 512MB/0MB RAM
| Part | Expansion Site/Bus | Analog Input:Output | Storage Interface | Ethernet [Max] | Ethernet [Min] | Watchdog Timer | Speed | Digital I/O Lines | Core Processor | RS-232 (422, 485) | RAM Capacity/Installed | Size / Dimension [y] | Size / Dimension [x] | Size / Dimension [x] | Size / Dimension [y] | USB | USB | Power (Watts) | Number of Cores [custom] | Operating Temperature [Min] | Operating Temperature [Max] | Form Factor | Video Outputs | Cooling Type | Analog Input:Output [custom] | Analog Input:Output [custom] | Number of Cores | Ethernet | Ethernet |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 VersaLogic Corporation | microSD mPCIe PC/104-Plus SATA SPI | 8:00 | microSD Mini PCIe/mSATA mPCIe/mSATA SATA | 100 Mbps | 10 Mbps | 933 MHz | 32 | Vortex86DX2 | 4 | 512 MB | 8 " | 146.05 mm | 5.75 in | 203.2 mm | 5 | USB 2.0 | 5.8 W | 1 | 0 °C | 60 °C | EBX | LVDS VGA | |||||||
 VersaLogic Corporation | CANbus mPCIe SATA SPX SUMIT | eUSB mPCIe/mSATA mSATA SATA 2.0 (2) SATA 3.0 (2) SATA3 (2) SATA6 (2) | 1.7 GHz 2.8 GHz | 32 | Intel Core i7-3517UE | 4 | 0 GB 16 GB | 8 " | 146.05 mm | 5.75 in | 203.2 mm | USB 2.0 (10) USB 3.0 (2) | 20.7 W | 0 °C | 60 °C | EBX | DP (2) LVDS VGA | Fan + Heat Sink Heat Sink | 16 | 8 | 2 | 2 10 Mbps 100 Mbps 1000 Mbps | |||||||
VersaLogic Corporation | microSD mPCIe PC/104-Plus SATA SPI | 8:00 | microSD Mini PCIe/mSATA mPCIe/mSATA SATA | 100 Mbps | 10 Mbps | 800 MHz | 32 | Vortex86DX2 | 4 | 512 MB | 8 " | 146.05 mm | 5.75 in | 203.2 mm | 5 | USB 2.0 | 5.8 W | 1 | -40 C | 85 °C | EBX | LVDS VGA | Heat Sink | ||||||
 VersaLogic Corporation | PC/104-Plus | eUSB MiniBlade SATA2 (2) | 1.2 GHz | 32 | Intel Core 2 Duo P8400 | 4 | 0 GB 8 GB | 8 " | 146.05 mm | 5.75 in | 203.2 mm | USB 2.0 (6) | 14.3 W | -40 C | 85 °C | EBX | LVDS (2) VGA | Fan + Heat Sink | 8 | 4 | 2 | GbE (2) | |||||||
 VersaLogic Corporation | PC/104-Plus | eUSB MiniBlade SATA2 (2) | 1.2 GHz | 32 | Intel Core 2 Duo P8400 | 4 | 0 GB 8 GB | 8 " | 146.05 mm | 5.75 in | 203.2 mm | USB 2.0 (6) | 14.3 W | -40 C | 85 °C | EBX | LVDS (2) VGA | Fan + Heat Sink | 8 | 4 | 2 | GbE (2) | |||||||
 VersaLogic Corporation | 104 CANbus mPCIe PCIe PCIe/104 SATA SPX | eUSB mPCIe/mSATA mSATA SATA 2.0 (2) SATA 3.0 (2) SATA3 (2) SATA6 (2) | 1.6 GHz | 32 | Intel Core i3-3217UE | 4 | 0 GB 16 GB | 8 " | 146.05 mm | 5.75 in | 203.2 mm | USB 2.0 (10) USB 3.0 (2) | 14.4 W | -40 C | 85 °C | EBX | DP (2) LVDS VGA | Fan + Heat Sink | 16 | 8 | 2 | 2 10 Mbps 100 Mbps 1000 Mbps | |||||||
 VersaLogic Corporation | PC/104-Plus | 8:00 | ATA-4 CompactFlash | 100 Mbps | 10 Mbps | 500 MHz | 32 | Geode LX 800 | 4 | 0 GB 1 GB | 8 " | 146.05 mm | 5.75 in | 203.2 mm | USB 2.0 (4) | 4.5 W | 1 | -40 C | 85 °C | EBX | LVDS VGA | Heat Sink | 8 | 0 |
